Need a box design QUICKLY!

[Beerdrnkr 5,000+ posts]

Can anyone help me with a ported box design for an 18". Here's the measurements I have to work with, I know it won't be optimal for an 18" but it's all the room I have. I'll pay somebody through paypal if need be.

22"H x 40 1/4"L x 21 1/4"W

Please help me out, Thanks.

Click to read more...



[psych0ticnemes1 5,000+ posts]

Slot ported or round ported?



[Beerdrnkr 5,000+ posts]

Slot ported or round ported?

Slot, in what ever configuration it will fit.



[revrider1 5,000+ posts]

WHat sub?



[Beerdrnkr 5,000+ posts]

WHat sub?

18" MT it kills me not to have the optimum space but hopefully 5 c/ft or so will work.



[iDesignBoxes 10+ year member]

desired tuning freq?



[iDesignBoxes 10+ year member]

i forgot to ask, what are the t/s specs of this driver? they are not listed on RE's website.



[Beerdrnkr 5,000+ posts]

desired tuning freq?

Here's some specs:

It's for an 18" MT

Mounting depth is 10.75"

displacement .25c/ft

Tuning I want at 32hz.

I'm not sure about the volume and maybe 90 to 100sq inches of port?



[iDesignBoxes 10+ year member]

one box design coming up sir. be back in a jiffy. gonna add .3 cubes to this box to account for bracing... this box will need it.



[Beerdrnkr 5,000+ posts]

one box design coming up sir. be back in a jiffy. gonna add .3 cubes to this box to account for bracing... this box will need it.

Cool, I appreciate the help.



[Beerdrnkr 5,000+ posts]

Sorry I might have my port too small it might be around 140sq inches.



[iDesignBoxes 10+ year member]



[galacticmonkey 5,000+ posts]

Go with less port... Try for around 70 sq in. When you have limited space its much better to have the right airspace than a monster port.



[80INCHES 5,000+ posts]

Go with less port... Try for around 70 sq in. When you have limited space its much better to have the right airspace than a monster port.

agreed

he can actually get away with 60square inches of port

it wont as long and it wont take up much space

80



[Beerdrnkr 5,000+ posts]

Go with less port... Try for around 70 sq in. When you have limited space its much better to have the right airspace than a monster port.

So in this case, the box that iDesign made is perfect for the amount of room I have right?
