2023 ram 5500 slt speaker wiring diagram

[Steven Lature]

Can somebody please tell me the wiring diagram and the wire colors for a 2023 Ram 5500 I need to know what's positive what's negative on the speaker wires I'm connecting a lc2i. I'm pretty sure there's not an amp but if there was could you tell me where it's at

Click to read more...



[rick619]

Not sure how helpful this is, but I have a 2023 1500 Big Horn with the base audio system. No idea if the 5500 is the same or different. At least with the 1500, there are three different audio systems: Base 6 speaker, Alpine (9 speaker) and HK.

No idea on wiring for the lc2i, I only do basic stuff like replacing speakers.

This site is probably the best place to look for Ram specific questions:

5th Gen General Discussion

General discussion for 2019+ Rams

5thgenrams.com

I also subscribe to a 5th gen audio Facebook group. They are very helpful, but can be a bit snobby at times if you're not using the brands they like:
