SOLD Rockford Fosgate T30001BD HUGE!REPAIR!

johnjv29
10+ year member

Member
I am selling my Rockford Fosgate T30001BD mono amplifier that is a MONSTER!This amp is rated at 3000 watts RMS @ 1 ohm and will push any sub out there.Its overall in good condition but someone has painted the top black but still looks pretty nice.It has some marks here and there.This amp powers on but has no sound,it doesnt go into protect.I brought this amp to the local repair guy and he replaced all of the power supply transistors,output transistors and the gate resistors and a new torride straight from fosgate for $100!Most of the parts in this amp have been replaced I just needed the cash and didnt have more to put into the amp,I assume it will be a cheap fix but the repair guys oscilloscope was broken at the moment and couldnt trace the signal.This amp is sold AS-IS and will not accept any refunds.If you have any questions just ask or make any reasonable offer! I have this listed on a few other forums and ebay so it may go quick,I sold it once for $375 but the knucklehead didnt pay!....Here are the specs:

* RMS Power Range : 1000-3000 Watts

* Number Of Channels: 1

* Maximum Power: 3000 Watts

* Low Frequency response: 20 Hz

* High Frequency Response: 300 Hz

* Built In Crossovers: Yes

* Channel Separation: Yes

Features

* 1000 W x 1 @ 4 Ohms RMS

* 2000 W x 1 @ 2 Ohms RMS

* 3000 W x 1 @ 1 Ohms RMS

* Total power 3000 Watts

* Bridgeable:Master Sync, Power Sync (bd-sync2)

* Crossover:LP 32-250Hz 24dB per Octave, Subsonic Filter 28Hz

* Tone controls:Bass Control, 0 to 18 dB @ 35-70 Hz

* Signal input: Low level - , Quantity - 1, Type - RCA(pr)

* Line output: 1 RCA(pr)

* Phase control: 0/180 degrees

* Power input: Connector - Block, Wire gauge - 1/0 AWG

* Speaker output: Block

* Heatsink: Type -Cast, Cooling -Fan Cooled

* Remote control: Included, Type - Wired, Controls - Bass

* Class B/D

* Dimensions: 2.6 X 12.8 X 33 (inches)
