Whats the pros and cons on using 13 ply? nice design. How much port area?

Birch is stronger and lighter but costs twice as much as MDF.



[iamamp3pimp 5,000+ posts]

yup

its easier to work with minus the splinters though //content.invisioncic.com/y282845/emoticons/frown.gif.a3531fa0534503350665a1e957861287.gif

but its got 40 square inches.

time to get some build pics up.......now only if photobucket was easy...



[bonesninja 5,000+ posts]

Birch is stronger and lighter but costs twice as much as MDF.

also, it's extremely nice to work with if you have plans to finish your box without carpeting. MDF is extremely hungry and eats paint like its going out of style



[bonesninja 5,000+ posts]

yup
its easier to work with minus the splinters though //content.invisioncic.com/y282845/emoticons/frown.gif.a3531fa0534503350665a1e957861287.gif

but its got 40 square inches.

time to get some build pics up.......now only if photobucket was easy...

i use http://www.villagephotos.com very easy to work with



[mazdakid 5,000+ posts]

imageshack.us is very easy



[iamamp3pimp 5,000+ posts]

im loving photobucket...i use flock. i was kidding about the difficulty, and i get to keep my album.

anyway here we go....just a few build pics....

or if you know me, a few is never enough,

heres the guide that i been using, and its for sale because i made my own.

and a little something else here

how i was originally going to do this port, but it proved to be much more difficult, and i had to take it apart before the glue dried.

that is the inside (port side) poece, with a port wall attached to it. i am glad that i changed it up, as it becme much easier.

just a mockup of the port insanity

and actually getting the first piece on.



[iamamp3pimp 5,000+ posts]

more pics comnig in a few.



[iamamp3pimp 5,000+ posts]

Here is the left side (looking at it straight on) with all the pieces attaches sans the side baffle.

and a few more pics of the other side.....pretty much both sides in

more coming.

tell me waht you think.



[bonesninja 5,000+ posts]

me likey



[thatkidbob 10+ year member]

is the dual port thing just for looks? because if not you could've made a smaller single port and saved a lot of internal space with lower vent velocities...

still though, it looks like quality wood work...



[bonesninja 5,000+ posts]

its quite pimp the way it is because each port will be firing directly through the ports in my rear deck. this is mostly an SQ set-up by the way



[saywhat? 5,000+ posts]

build looks good.



[iamamp3pimp 5,000+ posts]

and that kid bob, i looked ino it, because a single port would have been much easier, but im only losing a few cubic inches by doing it this way, so its really not going to make a difference. as far as the sound goes, it ont affect it at all.



[saywhat? 5,000+ posts]

pimp for vice president!

saywhat? for president!



[bonesninja 5,000+ posts]

to put this in perspective.....this box is going to sit up on the area where there is no carpet near the top of the photo. That area sits 5" above the floor of my trunk.

The rest of the trunk floor will be a false floor with the amps mounted below with plexi windows and some cool led lighting for the night show. On either side of the trunk, behind the wheel wells, there will be an extra battery. The batts will be hidden from view and the trunk will be nicely panelled up, alot like the Sound Werks Grand National
