Pioneer 2006 Headunit Lineup! *Pics*

[ndnbolla 10+ year member]

A friend who goes by the name of cartronics at icixsound.com was able to get his hands on some info of the upcoming 2006 Headunits.

Take a look:

DEH-1800

Feature List:

Improved Cosmetic

3-Band Equalizer

Super Tuner® IIID ™AM/FM Digital Tuner

Selectable Loudness Control

Front Image Enhancer

Source Level Adjustment

MOSFET 50 x 4-Channel High Power

Rear Pre-out (2v)

Blue-Back LED Display

Detachable Face Security

DEH-2800MP

Feature List:

WMA/MP3/WAV CD-ROM Playback

3-Band Equalizer

Super Tuner® IIID ™AM/FM Digital Tuner

Selectable Loudness Control

Front Image Enhancer

Source Level Adjustment

MOSFET 50 x 4-Channel High Power

Rear Pre-out

Blue-Back LED Display

Detachable Face Security

DEH-3800MP

Feature List:

WMA/MP3/WAV CD-ROM Playback

Supertuner®IIID ™AM/FM Digital Tuner

IP-Bus System Expansion

-Multi-CD Controls

- SAT Ready

- Ipod Ready (Ext.)

- Auxiliary Input with optional CD-RB10 or CD-RB20

CD Text with Auto-Scroll

EEQ™ Performance Chip

MOSFET 50 x 4-Channel High Power

Dual Pre-out

Two-Way Crossover

Direct Subwoofer Control

Card Remote

Large 16-Character Multi-color LED Display

Wired Remote Input

Detachable Face Security

DEH-4800MP

Feature List:

WMA/MP3/WAV CD-ROM Playback

Supertuner®IIID ™AM/FM Digital Tuner

IP-Bus System Expansion

-Multi-CD Controls

-SAT Ready

-Ipod Ready (Ext.)

-Additional Auxiliary Input with optional CD-RB10 or CD-RB20

CD Text with Auto-Scroll

EEQ™ Performance Chip

MOSFET 50 x 4-Channel High Power

Dual Pre-out

Two-Way Crossover

Direct Subwoofer Control

Card Remote

Large 16-Character Multi-color LED Display

Wired Remote Input

Flap Detachable Face Security

Click to read more...



[ndnbolla 10+ year member]

(continued...)

DEH-5800MP

Feature List:

Blue OEL with Red backlight

WMA/MP3/WAV CD-ROM Playback

Supertuner®IIID ™AM/FM Digital Tuner

IP-Bus System Expansion

-Multi-CD Controls

-SAT Ready

-Ipod Ready (Ext.)

-Auxiliary Input with optional CD-RB10 or CD-RB20

CD Text with Auto-Scroll

EEQ™ Performance Chip

MOSFET 50 x 4-Channel High Power

Three RCA Preouts

Two-Way Crossover

Card Remote

Wired Remote Input

Flap Detachable Face Security

DEH-6800MP

Feature List:

Large Blue OEL Display

Rotary Commander

iTunes AAC/WMA/MP3/WAV CD-ROM Playback

Supertuner®IIID ™AM/FM Digital Tuner

Aux Input

IP-Bus System Expansion

-Multi-CD Controls

-Full SAT Control Ready

-Full iPod Control Ready

-Auxiliary Input with optional CD-RB10 or CD-RB20

CD Text with Auto-Scroll

EEQ™ Performance Chip w/ 7-Band

Graphic EQ

Multi-Language Display

MOSFET 50 x 4-Channel High Power

Three RCA Preouts

Two-Way Crossover

Card Remote

Wired Remote Input

Flap Detachable Face Security

DEH-P7800MP

Feature List:

Supertuner®IIID ™AM/FM Digital Tuner

iTunes AAC/WMA/MP3/WAV Compatible

Built-In DSP w/16-Band EQ

Source Level Adjustment

Automatic Sound Levelizer

65K Color OEL Display, 256 x 64 pixels

Rotary Commander

Multi-Language Display

AUX Input

Spectrum Analyzer

IP-Bus System Expansion

-Multi-CD Controls

-DVD Control

-Full SAT Control Ready

-Full iPod Control Ready

-Additional Auxiliary Input with optional CD-RB10 or CD-RB20

CDR PC-Link Capability

-Gauge Display

MOSFET 50 x 4-Channel High Power

Three Hi-Volt Preouts (5V)

Ten Key Card Remote

Cellular Mute

Rotary Volume Knob

Rotary Commander

Wired Remote Input

Bit Media Expander

Auto Flap Motorized Mechanism

Auto Flap Detachable Face Security

Built-In DSP Feature List:

16-Band Graphic Equalizer (by DSP)

-Frequencies: 20, 31.5, 50, 80, 125, 200,

315, 500, 800, 1.25k, 2k, 3.15k, 5k, 8k,

12.5k, 20k

-Level: +/- 12dB

-5 Factory and 2 User EEQ™Presets, Super

Bass, Powerful, Natural, Vocal, Flat, Custom1,

Custom2

-Independent Custom Memory for each

source

-Loudness Control

B.B.E.

-Four selectable steps

Listening Position

-Front Right

-Front Left

-Front

-All

Time Alignment

-Adjustment range 0~160inch/0.5 inch steps

-4 Factory and 1 User Preset, Compact/SUV,

Sedan, Wagan, Mini-Van, Custom

Independent Two-Way Network

-Front HPF: 50/63/80/100/125/160/200Hz

Level: +0~-24/MUTE(1dB step)

Slope: -12dB/-6dB/0dB/Oct.

-Rear: HPF: 50/63/80/100/125/160/200Hz

Level: +0~-24/MUTE(1dB step)

Slope: -12dB/-6dB/0dB/Oct.

-Subwoofer LPF: 0/63/80/100/125/160/200Hz

Level: +6~-24/MUTE(1dB step)

Slope: –18dB/-12dB/-6dB/Oct.

Phase: (Normal/Reverse)

Automatic Sound Levelizer

Burr Brown 24 Bit DAC’s

DEH-P9800BT

Feature List:

Same as DEH-P7800MP except for Bluetooth Connectivity

Bluetooth Features:

Caller ID

-Read Color OEL display for in coming calls

-Name and number displayed if in phonebook storage

-Audio Mute

-Mutes audio System and imports cellphones’ ringer

Phonebook Storage

Contact can be called up and dialed by name

Five users:

User 1 (100 contacts)

User 2 ( 50 contacts)

User 3 ( 50 contacts

Built-In DSP Feature List:

Same as DEH-P7800MP



[XtrmAudioCncpts 10+ year member]

nice. i like the 7800 and the 9800



[nissanrider06 10+ year member]

//content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif thanks!!!



[Savstyle 10+ year member]

nice. i like the 7800 and the 9800

//content.invisioncic.com/y282845/emoticons/word.gif.64b12e39f936af3b4fff38a1c0bd0244.gif



[loudblazer02 10+ year member]

**** the last 2 look sexy.



[slick316 10+ year member]

Bluetooth phone capability built into the headunit, I like that feature a lot.

I really don't care for Pioneer products, but those HU's are nice, I think they did a good job.



[flakko 5,000+ posts]

that phone book thing is cool

i also like the look of the lower end HUs (the first two) nice an simple



[Insaneman1731 10+ year member]

On looks I like the 6800.



[XtrmAudioCncpts 10+ year member]

i have no real need for the bluetooth so i would probably get the 7800



[Eugenics 5,000+ posts]

wow, those dont ****



[DiamondFanatic 10+ year member]

wow, those dont ****

Yeah I'm with you.

Looks like I won't be getting another Pioneer anytime soon, the Rotary Commander is quite possibly the stupidest idea ever IMO. Oh well...



[JAZN 5,000+ posts]

Not too shabby. The button layout on the upper end models are rather interesting.



[btnhfan 5,000+ posts]

Man their new products look great.



[ndnbolla 10+ year member]

I myself am looking forward to their DVD/Navi units, that is if their will be a new model for '06.
