Picture(s) of your setup(s) as it(they) sit(s)!

[MisterDeadeye 10+ year member]

Pardon my ignorance if we've already got one of these topics.

Anyway, the concept is simple -- take a picture of your trunk, back seat, wall, hatch, cargo space, doors, head unit, etc. as it sits. I'm interested in seeing how people have their subs/ports oriented, and what everyone's got going on for mids and highs.

If you don't have a camera, don't worry! You can write(in paragraph form, preferably) about what you've got.

As for me, I'm broke with no job, and I don't have a substage. I've got a pair of ID CTX65s(yes, coaxials) up front powered by an older Power Acoustik two channel, and I've got a pair of Morel Maximo 6x9s in the back powered by my Pioneer DEH-P4000UB. I'll post a picture tomorrow.

Click to read more...



[THATpurpleKUSH 5,000+ posts]

Box is getting rebuilt in a few weeks after I'm done with finals.



[hispls 5,000+ posts]

Hurp Derp. ITT ask everyone to run out and take pictures at midnight.



[I Like Waffle]

HU is a pioneer 6100ub. Door speakers are Premier comps up front, premier 3 way 6x9s in the back. Sub stage is a pyramid PWX15 in 4cf net @ 32hz or a 12" infinity kappa perfect in 2.2cf @ 33hz. I swap them out depending on trunk space i need. Amp is a Orion cobalt co600.2. Does about 600w rms. This is in the daily car, its pretty decent. Have much bigger things in other rides that are under construction.



[audiobaun 5,000+ posts]

98 Xcab Chevy

2-redtops

1-Kinetik HC600-Have will be added shortly

1-250 ANL-JL fuse holder

1-255amp alternator from AlterStarts in Dallas,Tx

2ga Power wire/JL

2-stinger fans

1-stinger 4 AGU Dist block

1-Stinger 2/or 4 AGU dist block have ,and will add or sub amps

Old school Eclipse CD3000 HU with power Adapter

1-Kicker KQ9 preamp

1set of old school Audiobahn ABC60003-360rms 3way comp

1 set of old school Audiobahn ABC6002-200rms 2way comp

1 set of Infinity 100rms Tweets(1in)

1set of 50rms Infinity tweets(3/4 in.)Have and will be added

1-Old school Autotek BTX 7204 4ch(Zed)30amp fused

1-Old school Autotek BTS 7050 2ch(Zed) Have and will be added 25amp fused

2-Old school Autotek BTS 7150 bridged at 2ohms(ZED)(1 on each pair of subs)40amp fused ea.

4-Old School DISCONTINUED Audiobahn AW 1008t DVC2ohm-1000rms/2000pk 10in 240oz doubled stacked magnet subs-Working on now at 1.6cuft ported per sub

All amps will retrieve 8ga Power wiring, is all that is needed

Regrouping my Theft recovery atm,on another pair of subs with a new box, as the other was destroyed, and subs ripped out, and different set of amps.Had the Audiobahn HCT 4125 on mids and highs, and the 18001DT at !ohms on the subs,Still have the amps, but dropping back down to a 2ohm load this time on all old school Zeds

When completed,Hopefully by end of the month, Pics to follow



[CAT MAN 5,000+ posts]

HU is a pioneer 6100ub. Door speakers are Premier comps up front, premier 3 way 6x9s in the back. Sub stage is a pyramid PWX15 in 4cf net @ 32hz or a 12" infinity kappa perfect in 2.2cf @ 33hz. I swap them out depending on trunk space i need. Amp is a Orion cobalt co600.2. Does about 600w rms. This is in the daily car, its pretty decent. Have much bigger things in other rides that are under construction.

i have to hear the pyramid...........those were the first beasts from them and the only ones



[I Like Waffle]

i have to hear the pyramid...........those were the first beasts from them and the only ones

You would be correct sir. I used to have 2 of them ported on an M1000 in a trunk car and completely destroyed a local guy at a comp who had 2 L7 15s on a ZX1500 in a PT loser.



[CAT MAN 5,000+ posts]

You would be correct sir. I used to have 2 of them ported on an M1000 in a trunk car and completely destroyed a local guy at a comp who had 2 L7 15s on a ZX1500 in a PT loser.

i had a chance to get the 8s for 40 bucks (20 ea) and i dont know why i didnt get them



[hispls 5,000+ posts]

You would be correct sir. I used to have 2 of them ported on an M1000 in a trunk car and completely destroyed a local guy at a comp who had 2 L7 15s on a ZX1500 in a PT loser.

Were those the ones made by Emminence? Some solid drivers if they're the ones I'm thinking of....just goes to show, even a blind squirrel gets a nut now and again



[Ninesvnsicks 10+ year member]

I have everything listed in my signature //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif I really need to mount my 4 channel amp lower.



[OmegaBunny 10+ year member]



[R34P3R 10+ year member]

Soundstream VIR-7830

Sundown 1500D, Sundown 100.4, Audiocontrol Epicenter

18" Old School RE XXX Reconed Courtesy of Slim2FattyCake

8.25Ft^3 @ 33Hz With Angled Corners and Kerfed Port Courtesy of Slim2FattyCake

Kinetik HC2400 Secondary

Don't have any picks of dynamating or the RF T1 Coaxials in all four doors. Also have a Clarion eq in the dash with the epicenter controls.



[Ninesvnsicks 10+ year member]

Soundstream VIR-7830

Sundown 1500D, Sundown 100.4, Audiocontrol Epicenter

18" Old School RE XXX Reconed Courtesy of Slim2FattyCake

8.25Ft^3 @ 33Hz With Angled Corners and Kerfed Port Courtesy of Slim2FattyCake

Kinetik HC2400 Secondary

Don't have any picks of dynamating or the RF T1 Coaxials in all four doors. Also have a Clarion eq in the dash with the epicenter controls.

Doesn't the rear hatch block your port?



[R34P3R 10+ year member]

Doesn't the rear hatch block your port?

Its about 3-4" away from the hatch, but it still gives respectable output so it doesn't really bother me.



[Ninesvnsicks 10+ year member]

Its about 3-4" away from the hatch, but it still gives respectable output so it doesn't really bother me.

oh ok looks closer in the picture. I still wish i put my subs on top maybe in the spring.
