Is this a good battery diagram/battery bank

[hrtbrk1 5,000+ posts]

is this a good way to wire multiple batterys?

Click to read more...



[Buck 5,000+ posts]

Looks pretty good to me.



[hrtbrk1 5,000+ posts]

Looks pretty good to me.

thanks buck...can i ditch the long ground and just ground to chassis cuz i got a unibody or stick to what i have?



[Buck 5,000+ posts]

Um, just stick to what you have I guess. Or do both. Lol batteries are just supposed to be + to -.



[IDSkoT 5,000+ posts]

I never understood how people can't figure out how to wire multiple batteries. Positive to positive, negative to negative. It's... not hard.



[hrtbrk1 5,000+ posts]

Um, just stick to what you have I guess. Or do both. Lol batteries are just supposed to be + to -.

oh lol i meant the main battery -..can i ditch that and just like ground one of the battery banks - to the chassis and link it like the pic? wait do u want me to draw a pic?



[Xprime4 10+ year member]

worst draw ever //content.invisioncic.com/y282845/emoticons/confused.gif.e820e0216602db4765798ac39d28caa9.gif

you don't have to ground loop. Just find a nice spot on the car frame to ground



[hrtbrk1 5,000+ posts]

like this

http://img14.imageshack.us/img14/7293/batteryf.jpg



[hrtbrk1 5,000+ posts]

I never understood how people can't figure out how to wire multiple batteries. Positive to positive, negative to negative. It's... not hard.

its called the noobz..lol



[Xprime4 10+ year member]

I never understood how people can't figure out how to wire multiple batteries. Positive to positive, negative to negative. It's... not hard.

they aren't complicated, but they can be dangerous if done in a wrong wasy //content.invisioncic.com/y282845/emoticons/rolleyes.gif.c1fef805e9d1464d377451cd5bc18bfb.gif



[hrtbrk1 5,000+ posts]

worst draw ever //content.invisioncic.com/y282845/emoticons/confused.gif.e820e0216602db4765798ac39d28caa9.gif
you don't have to ground loop. Just find a nice spot on the car frame to ground

ground loop?



[Buck 5,000+ posts]

oh lol i meant the main battery -..can i ditch that and just like ground one of the battery banks - to the chassis and link it like the pic? wait do u want me to draw a pic?

Do both. And use bus bars.



[Xprime4 10+ year member]

ground loop?

I meant your back battery grounds don't need to be grounded at the front batt.

i'm french //content.invisioncic.com/y282845/emoticons/furious.gif.fc81ca146dbff91fede3ed290dbc4f4c.gif sorry about confusion



[Buck 5,000+ posts]

I meant your back battery grounds don't need to be grounded at the front batt.
i'm french //content.invisioncic.com/y282845/emoticons/furious.gif.fc81ca146dbff91fede3ed290dbc4f4c.gif sorry about confusion

It wouldn't hurt though to have both //content.invisioncic.com/y282845/emoticons/fyi.gif.9f1f679348da7204ce960cfc74bca8e0.gif



[BushJ311 5,000+ posts]

I never understood how people can't figure out how to wire multiple batteries. Positive to positive, negative to negative. It's... not hard.

Maybe they are not sure. I know i would not want to mess up wiring a battery in my car. Never hurts to ask.
