Build Member FI Q 12" 2.25 @ 32 Hz

[rpfuror 10+ year member]

Heres worklog for a box I'm building for a forum member for a FI Q 12" 2.25 cu/ft Net @ 32 Hz.

3D Drawing:

Box Cutts:

Back and Bottom:

Port Side:

O Port Side:

Port Side Painted:

Port Cuts Rounded:

Port Construction:

More To Come.....

Click to read more...



[RAINMAKA 10+ year member]

Is it ok to put a 12" sub in the side that is 15"? I was curious about that when trying to design a box but didnt know if that is enough space. Sorry to hijack but looks good.



[ultimate157 5,000+ posts]

Is it just me or did you paint the contact surface where the port wall goes? That will cause the glue to not bond correctly.



[rpfuror 10+ year member]

Is it ok to put a 12" sub in the side that is 15"? I was curious about that when trying to design a box but didnt know if that is enough space. Sorry to hijack but looks good.

I have never hade a problem with this. Typically the 12" cut size is 11.2" this give you over an inch to work with on top and bottom.

Is it just me or did you paint the contact surface where the port wall goes? That will cause the glue to not bond correctly.

You are correct that the paint is in an area of the box that I mounted one of the port walls, but I used a sander to clean it up before putting it together. It sill not leak.



[bama350z 10+ year member]

ygpm



[billabongcr 5,000+ posts]

nice box



[ultimate157 5,000+ posts]

Is it ok to put a 12" sub in the side that is 15"? I was curious about that when trying to design a box but didnt know if that is enough space. Sorry to hijack but looks good.

Na not a problem, as long as you use a double front baffle. My 12" is mounted on a face that is only 12.5" across (due to calculation error) however I made up for it by using a second baffle for extra support

You are correct that the paint is in an area of the box that I mounted one of the port walls, but I used a sander to clean it up before putting it together. It sill not leak.

Ok cool, box looks great.



[PV Audio 5,000+ posts]

If I may be so blunt, but is the member paying for this box?



[bama350z 10+ year member]

yes, i'm paying for it..why do you ask??



[RAINMAKA 10+ year member]

Na not a problem, as long as you use a double front baffle. My 12" is mounted on a face that is only 12.5" across (due to calculation error) however I made up for it by using a second baffle for extra support

Do you a picture of a second baffle I think I know what it is put not positive. I want to use a 12" BTL which has a ouside diameter of 12.5" and put in a side of the box that is 15". I should be ok with that?



[mazdakid 5,000+ posts]

yes thats more than enough height for a 12



[bama350z 10+ year member]

this is what it's going in....................



[rpfuror 10+ year member]

mmmmmm... old broncos



[rpfuror 10+ year member]

If I may be so blunt, but is the member paying for this box?

yeap bama350z is paying for it, Basically supplies and shipping (shipping is the majority of the cost). Sorry if it is not up to your standards (again)



[PV Audio 5,000+ posts]

Ok.
