Wiring.

[Ku-sama]

does this look right?

R is for RCA...

sorry for the sloppyness

Click to read more...



[bubbagumper6 5,000+ posts]

are you serious?



[Railrocker 10+ year member]

Awwww you made smilie faces out of your subwoofers.



[Ku-sama]

???



[DeViOuSoNe 10+ year member]

I cant understand it...Try doing it a little neater next time



[DeViOuSoNe 10+ year member]

And what in the HELL are the things at the bottom right?

OK I see

The only thing i see a little fucxed up is the wiring on the CRUNCH amp to sub



[bubbagumper6 5,000+ posts]

well the only advice i can offer from that diagram is that you dont need a distro for your ground...or you can if you want you just dont need to run it all the way back to your battery...just drill a hole in your trunk and ground to the chassis. You can still use the distro and just ground the 1 larger wire.



[Ku-sama]

well it's just that I have plenty of 4 gague and like 20 feet of 8 gauge... plus I don't feel like making a ground....

that's what I got for the subs for 4 ohm...



[bubbagumper6 5,000+ posts]

O_O

you don't feel like making a ground???

wow - exactly how long is your ground wire going to be, going all the way back to the batt?



[Ku-sama]

yup.... its going in the S-10 so its only like 6 feet from the batt



[bubbagumper6 5,000+ posts]

and ground wires are recommended to be what 3 feet?

so since you don't feel like drilling a hole and attatching a ring terminal your sacrificing current...



[TIeclipseMOJO 10+ year member]

your deck only has 1 set of RCA outputs?



[k12ug 10+ year member]

does this look right?

R is for RCA...

sorry for the sloppyness

i did the same thing when i was trying to learn about all of this stuff....lol

good job



[Ku-sama]

and ground wires are recommended to be what 3 feet?
so since you don't feel like drilling a hole and attatching a ring terminal your sacrificing current...

meh, 4 gauge ftw... I have the ring terminals...

your deck only has 1 set of RCA outputs?

that's cheap JVC for ya

i did the same thing when i was trying to learn about all of this stuff....lolgood job

sweet, I'm not alone



[Atimm693 10+ year member]

What is the pre out on HU?

Sub, front, rear?



[JeremiahCoffel 10+ year member]

Grounds are recommended to be no longer than 18"?



[htownplaya456 10+ year member]

oh god not ku-sama again trying to act like he knows what hes doing........................................//content.invisioncic.com/y282845/emoticons/hilarious.gif.02a037aad04aa96f19982b298a3d70a8.gif



[Atimm693 10+ year member]

Grounds are recommended to be no longer than 18"?

I though it was 36"........



[htownplaya456 10+ year member]

I though it was 36"........

well the shorter the better



[Ku-sama]

Grounds are recommended to be no longer than 18"?

so would it hurt my piece of crap system to run a ground back to the battery?

oh god not ku-sama again trying to act like he knows what hes doing........................................//content.invisioncic.com/y282845/emoticons/hilarious.gif.02a037aad04aa96f19982b298a3d70a8.gif

if I knew, would I ask? I never said I knew everything. I know enough to get me by.... but ask me anything about computers and I can answer it //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif

I though it was 36"........

Wiki??

well the shorter the better

hows 6'?
