What terminals are what on Adire audio Koda passive?(pics)

[supermaxx123 10+ year member]

I bought this comp set and it didnt have any sort of instructions and i cant find them online.

so which is which?

I'm guessing starting from left to right its, input, mid, tweet. im going to test either way but maybe someone can make it easier, it wierd that they are not labled and i cant take the board out to see where the terminals go to.

Click to read more...



[keep_hope_alive Premium Member]

why can't you take the board out? use a DMM to determine the traces. then you can develop the wiring diagram and determine how the two 12dB/oct crossovers are wired. the resistor should be on the tweeter section.



[tristanmay 10+ year member]

that sucks...

try taking the board out and see what terminal goes to what component?



[supermaxx123 10+ year member]

im sure it's glued down, they are new and don't want to risk breaking it. I will do the dmm test, idk why I didnt think of that... thanks!



[JimJ 5,000+ posts]

Simple way to avoid this...bi-amp actively //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[Wingman0121 10+ year member]

You can talk to the store Robot Underground on eBay, they bought out Adire and TC Sounds so they'll probably have diagrams of it.



[Pillow 10+ year member]

If for any reason you do not want the Koda set please let me know!

I am rocking a old Adire Brahma and would like to get the matching Adire comps.

Thanks! (back to lurking)



[supermaxx123 10+ year member]

I am running active and as far as selling them, make an offer. I'm curretly looking to buy some other mids that should work better in small sealed enclosures.
