Item(s) for Sale:
Used Taramps HD10000
Item(s) Description/Condition:
This amp was purchased from Senchez "Sencheezy" Richardson in April 2016 and has only been used once for 30 minutes of testing at the TDH Jeff Lockhart Memorial Show.
Physical: 7/10
Mechanical: 9/10 (only b/c I misplaced a few set screws)
The amp works flawlessly. The only thing wrong with it is that it is missing a few of the set screws which I have attempted to show via the pics below.
Taramp's HD 10,000 Amplifier
The Taramps HD 10,000 is a new and improved addition to the HD series, replacing the previous 10k offering. Improvements include but are not limited to the addition of line out, a deeper power supply down to 9v, more efficient heatsink up to 10 degrees Celsius cooler, and components which are more durable against damage from vibration. These models also have a better low impedance and thermal protection circuit. An on-board voltmeter was also added. The amplifier's new method of component adhesion was tested for 48hrs straight and then checked for vibration damage and passed.
This is a true 10,000 watt amp. The new HD series amps are some of the best amps from Brazil!
Specifications:
Number of Channels: 01
Maximum Power @ 13.8 VDC - 1 OHM: 11995W RMS
Maximum Power @ 13.8 VDC - 2 OHMS: 8037W RMS
Maximum Power @ 13.8 VDC - 4 OHMS: 4661W RMS
Maximum Power @ 12.6 VDC - 1 OHM: 10000W RMS
Maximum Power @ 12.6 VDC - 2 OHMS: 6700W RMS
Maximum Power @ 12.6 VDC - 4 OHMS: 3886W RMS
Input Sensitivity: 250mV @ (-9.78 dBm)
Total Harmonic Distortion (THD): 0.3%
S / N ratio:> 95dB
Damping Factor: 450
Frequency Response: 5Hz to 15kHz
Crossover:
HPF (High Pass Filter): 5 Hz to 50 Hz (-12dB / 8th) Variable
LPF (Low Pass Filter): 50Hz to 15kHz (-12dB / 8th) Variable
Protection System: Short in output / High Supply Voltage / Low / Thermal Protection
Input Impedance: 18K OHMS
Minimum Power supply: 9VDC
Maximum Supply Voltage: 16VDC
Idle Consumption: 3.60 Amp.
Maximal Musical @ 12.6VDC: 539.5 Amp.
Maximum consumption in sinusoidal signal (1kHz) @ 12.6VDC: 1079 Amp.
Dimensions (WxHxD): 230 x 73 x 497mm
Weight: 6.7kg
Price:
$750
Shipping and Miscellaneous Item Information:
Shipping & Insurance Included within the US
Item Pictures:
