Scion Tc Install

[JBLCAMRY 10+ year member]

I got a little caught up installing, and forgot to take pics of the door speakers and deck install. but i have some pics of the amp and enclosure when finished.

The equipment:

Deck: PIONEER DEH-P6900UB

Amp : KICKER ZX700.5

Front Speakers : RSD65CS

Rear Speakers : RSD6.5

Sub : MB QUART RWE304 12"

Oh, and it sounds damn good

Click to read more...



[mr_kebo 10+ year member]

Whats the Max Dimensions of the hatch area? My buddy is picking his up this friday



[JBLCAMRY 10+ year member]

Whats the Max Dimensions of the hatch area? My buddy is picking his up this friday

im not quite sure, because i was not ALLOWED to use the whole area. But the box is 16" wide, the amp rack is 22", so it is close to 38" wide. The box shown is 10 3/4 " tall x 21" on top.



[mr_kebo 10+ year member]

Think if you had time you could measure it up for me. He will will be needing a design for 2 12" DD 3512 ported.



[JBLCAMRY 10+ year member]

Think if you had time you could measure it up for me. He will will be needing a design for 2 12" DD 3512 ported.

Ill see if i can get him back over here tomorrow.



[mr_kebo 10+ year member]

oh sorry i was thinking it was your vehicle.



[EGGmane 10+ year member]

that looks good, i like how there is still room for cargo!



[JBLCAMRY 10+ year member]

that looks good, i like how there is still room for cargo!

//content.invisioncic.com/y282845/emoticons/biggrin.gif.d71a5d36fcbab170f2364c9f2e3946cb.gif

that was one of the main goals in this install.



[nittanylion64 10+ year member]

What do you think of the MB Quart Sub? I have 3 to put in my Explorer.

Thanks



[EGGmane 10+ year member]

//content.invisioncic.com/y282845/emoticons/biggrin.gif.d71a5d36fcbab170f2364c9f2e3946cb.gif
that was one of the main goals in this install.

i hear ya, i wish i coulda done that with my blazer. i got the big *** spare tire in the back taking up half the space than my box taking up another quarter, so there's not much room for anything else...



[Mr Cabinetry 10+ year member]

Whats the Max Dimensions of the hatch area? My buddy is picking his up this friday

I took these measurements of a Scion tC for an enclosure I will be building for a customer for a SI Mag 15 Ported:



[Witty690 10+ year member]

****, clean install.

BTW, im diggin that design^^^



[AVSTANG02]

those scions have such lame interiors.



[Mr Cabinetry 10+ year member]

****, clean install.
BTW, im diggin that design^^^

Just to let ya know that design had to be modified as to the top height of the point where to you see the slot ports on the front. If I used the actual height of 18", those ports openings would of been firing directly into the rear seat headrests.

So the angle of the top was increased to clear the top of those headrests.

And just for clarification as the dimensions I put up, that top angle is spaced a good 4" away from the hatch, I used the angle of the interior molding trim seam between the hatch and interior.

Best advise I would give here is to make a cardboard template of the enclosure's side profile and use that to make any adjustments as necessary as to fit in the install area.



[lbjshaq2345 10+ year member]

Biggest rectangular box that will fit is a 3' wide x 2' deep x 1' high. I have three 12s firing up @ 500w a piece. Sounds great.
