Design for JMulholland14

[bumpin buick 5,000+ posts]

Box is for a Ford Ranger

DC Lvl 5 18"

Cactus 5k

External Dimensions are W:48 D:16 H:22

Cutout is 16.75"

6.5cubes before sub displacement, estimated 6.2 with sub

Tuned to 35hz, estimated 37hz with sub in

101.5sq in port

Front: 48x22

Back: 48x22

Left: 21.25x14.5

Right: 20.5x14.5

Bottom:48x14.5

Top: 40.25x14.5

Port wall: 13.5x14.5

Click to read more...



[DonH 5,000+ posts]

hope he didnt pay and ur poting it all up on here! lol but looks alot like the box ima do for my 3518



[bumpin buick 5,000+ posts]

no, why would i charge people?

ive gotten donations after people have built them cause there happy but I just put it up here in case others want something like it or similar gives them something to work off of.



[SELFMADE]

your sketchup pro is expired //content.invisioncic.com/y282845/emoticons/fyi.gif.9f1f679348da7204ce960cfc74bca8e0.gif Lol just messing with ya nice design!



[TnT_Sounds 10+ year member]

single baffle FTW

//content.invisioncic.com/y282845/emoticons/laugh.gif.48439b2acf2cfca21620f01e7f77d1e4.gif



[406er 10+ year member]

i dont like the "estimated" net volume and tuning. but looks loud



[bumpin buick 5,000+ posts]

single baffle FTW

//content.invisioncic.com/y282845/emoticons/laugh.gif.48439b2acf2cfca21620f01e7f77d1e4.gif

He is doing double baffle and bracing I just didnt put that in there for him.

i dont like the "estimated" net volume and tuning. but looks loud

its pretty dead on but its like .374873021 and I didnt want to put that so maybe rounded is a better word to use then estimated?



[DonH 5,000+ posts]

no, why would i charge people?
ive gotten donations after people have built them cause there happy but I just put it up here in case others want something like it or similar gives them something to work off of.

just saying lol but looks great man! how u like sketchup pro?



[bumpin buick 5,000+ posts]

never really used the additions in pro, not something i found needed for building boxes. Just downloaded it to see what it was about.



[DonH 5,000+ posts]

never really used the additions in pro, not something i found needed for building boxes. Just downloaded it to see what it was about.

oh i c...

i thought about purchasing it just for the heck of it



[BASS14 10+ year member]

box is done! the only thing i changed is the sub is all the way to the left, and yes its double baffled and a 2x4 in the middle, with L brackets in the in the joints, 45s in all corners. the box weighs bout 120lbs so its a pretty stout box. i get the sub wednesday so ima felt it and install then. so there are pics comming on wednesday of everything done and installed.

thanks again bumpin!



[bumpin buick 5,000+ posts]

cant wait to see what ya think man, let me know and post up pics if you get the chance



[BASS14 10+ year member]

for sure there will be pics of everything done and installed on wednesday. hopfully a vid or 2 as well.



[mobeious 10+ year member]

ughh 6.5 at 37hz port should be 22.25"

that box looks to be tuned at 45



[bumpin buick 5,000+ posts]

all the calculators I have used have shown right around 35, give or take a 1+/-

I dont do it all out by hand but maybe I should try that, thing is every box ive ever built using the calculators has been near dead on. Not challenging you on it just curious if you did it by hand or used a program.
