Box design for L7

[BassHead99 10+ year member]

Im wanting about 3ft^3, and around 34hz or so. Its for a single L7 and space isnt an issue, I have plenty of room to work with. Can anybody help me out?

Click to read more...



[Atimm693 10+ year member]

Sure.

Subs up port back im assuming?

12 inch?



[Atimm693 10+ year member]

Here you go. Specs are 3.2ft^3@34htz. 3 inch port 22" long.

Cuts:

Top and Bottom: 31.5x 18.5

Back: 31.5x 13

Front: 29.75x 13

Left Side: 17.75x 13

Right side: 17x 13

Port 1: 13.25x 13

Port 2: 7.25x 13

Pics:



[Lakota 5,000+ posts]

Here you go. Specs are 3.2ft^3@34htz. 3 inch port 22" long.Cuts:

Top and Bottom: 31.5x 18.5

Back: 31.5x 13

Front: 29.75x 13

Left Side: 17.75x 13

Right side: 17x 13

Port 1: 13.25x 13

Port 2: 7.25x 13

Pics:

That was pretty **** generous of you.



[BrianChia 10+ year member]

It was very nice of you to do the design. Not trying to be rude but the port length is actually measured as 27.25" (you measure down the center of the port and add 1/2*width for "end correction"). It will lower the tuning (probably around 30hz) but its not a really big deal.



[Atimm693 10+ year member]

That was pretty **** generous of you.

Tonight i was bored as hell, not to mention im doing this for experience and practice. Im also trying to get my rep up before i start to charge people.



[BassHead99 10+ year member]

Tonight i was bored as hell, not to mention im doing this for experience and practice. Im also trying to get my rep up before i start to charge people.

That was very generous of you. I dont want to sound like a d*** but i actually have two and im getting one fixed (broken tensil lead). Do you think you could play around with a design for two 12"s? Same freq. just double the volume. If you could that would be awesome. Thanks again man!



[Atimm693 10+ year member]

That was very generous of you. I dont want to sound like a d*** but i actually have two and im getting one fixed (broken tensil lead). Do you think you could play around with a design for two 12"s? Same freq. just double the volume. If you could that would be awesome. Thanks again man!

Tomorrow afternoon ill get right on it. //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[BassHead99 10+ year member]

Tomorrow afternoon ill get right on it. //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif

Thanks again. So what was the port length supposed to be? Is it 27.25"?



[BrianChia 10+ year member]

I got 27.25" of port at 3.36 cf net. If the net displacement is 3.2 assuming 0.16 for the sub, it should tune to 29 hz.



[Atimm693 10+ year member]

Port should be 22" long.



[Atimm693 10+ year member]

Shit, just realized i measured the port wrong. Knock 1.5" of the second panel of the port to fix it. So it should be 5.75x 13.



[BrianChia 10+ year member]

Measure down the line through the center of the port, adding 1/2*port width at the end if using the wall of the box as a side of the port.



[Atimm693 10+ year member]

Lol i missed your little post above. WiniSD said that i needed 22" of port to tune to 34 htz. Also thanks for correcting me and for the 1/2" tip. //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif

OP im working on the design for both now, ill PM you when finished.



[vetkilr 10+ year member]

You need to have at least 40 sq of port.....50 if you like it low and loud.
