Bad noise with subwoofer @ high volumes

[bikinpunk 10+ year member]

Video Link

It makes a thud sound and I'm not sure if it has to do with my subwoofer bottoming out, the enclsosure size, or the fact that I only have a 3/4" baffle. I've been told that adding a double baffle will fix this issue, but I wanted to make sure it's not more than that before I do.

Thoughts?

Click to read more...



[iamamp3pimp 5,000+ posts]

box tuned really low, sub is probably bottoming out



[J31Rob 5,000+ posts]

Distortion?



[Warbleed 10+ year member]

It's got nothing to do with your baffle. It's either clipping or the woofer bottoming out. You're overdriving your speaker, just back off of it a bit.



[bikinpunk 10+ year member]

I took it out of the car, and pushed in on it about as far as I could. I didn't hear anything at all, no scraping, no touching, nothing. I'm about to take the woofer out and inspect around it, but just wanted to put that up so I can get some more ideas generating.

Anything coming to mind here to check?

I really wonder if the front baffle just isn't thick enough. //content.invisioncic.com/y282845/emoticons/confused.gif.e820e0216602db4765798ac39d28caa9.gif



[bikinpunk 10+ year member]

It's got nothing to do with your baffle. It's either clipping or the woofer bottoming out. You're overdriving your speaker, just back off of it a bit.

Gain was set with a DMM. It's supposed to be output @ 54.7 Volts but dialed in to 52 volts, and the subwoofer level on the h/u is 10/15, but set using 12/15.



[blackbonnie 5,000+ posts]

your baffle has nothing to do with it



[bikinpunk 10+ year member]

Looked inside, pushed on the woofer, checked everything and nothing seems out of the ordinary.

Here's a vid.

Here's a picture of the wiring & box. It's possible the wires were touching in there, but I doubt it. It just makes a very loud boom.



[ThatChevyGuy 5,000+ posts]

Wait it makes a boom? lol its a SUB. i couldnt see the problem?! you push on it that hard and ya its gonna do that. put it back in and turn your stuffs down a bit. Maybe a SSF? box is awful low.



[skadude016 5,000+ posts]

try free airing the woofer to see if it still makes the sound //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif
