psychoacoustics 10+ year member
hammer and the evil one
Item(s) for Sale:custom one of a kind 15 atomic /americanbass
one of a kind old school atomic Manhattan basket newer apx vfl motor upgraded softparts
sad to see this go its really cool
2. Specs:
brand new build hybrid woofer totally unique
Item(s) Description/Condition:5" manhattan basket powder coated with high gloss white not a scratch on it anywhere( this basket will not fit a regular gasket its slightly larger than a 12 spoke)
dual .35 coil flat wound 4 layer light weight coil
one piece dustcap cone cover
paper cone
long twisted pair blue and silver 10 awg direct leads
dual stitched tinsels connections crimped with copper terminals
dual stiff spiders
2kw rms aprox? depending on box application and amp
t/s parameters:
all measurements with coils in series
tested with the wt2 shown in last pic
Re = 0.8888 ohms (coils in series)
Fs = 41.7580 Hz
Zmax = 11.8545 ohms
Qes = 0.7676
Qms = 9.4701
Qts = 0.7100
Le = 0.7792 mH (at 1 kHz)
Diam = 381.0000 mm ( 15.0000 in )
Sd =114009.1866 mm^2(176.7146 in^2)
Vas = 63.9707 L ( 2.2591 ft^3)
BL = 11.2866 N/A
Mms = 419.2982 g
Cms = 34.6447 uM/N
Kms =28864.4297 N/M
Rms = 11.6169 R mechanical
Efficiency = 0.5702 %
Sensitivity= 89.5783 dB @1W/1m
Sensitivity= 99.1211 dB @2.83Vrms/1m
Price:300 shipped
Shipping and Miscellaneous Item Information:shipped right very good packing and insured to or above the sale price
