A real fuse block *pics*

[Lakota 5,000+ posts]

Just thought that I'd share

Click to read more...



[Side Show 10+ year member]

but why?



[Millertime1028 10+ year member]

lol what is that bohemoth fused on ?



[Lakota 5,000+ posts]

but why?

We have our little tricks in MECA to keep our fuses from popping. The photo really gives all the hints away.



[Millertime1028 10+ year member]

250- 300 amp ?



[Lakota 5,000+ posts]

250- 300 amp ?

Quite a bit less. Actually, 3 times less that that



[skateboardkid 10+ year member]

or he is running a 50 ampre class and is running 20 x 2.5slow blow fuses so he can get some # with the correct fusing

//content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[Millertime1028 10+ year member]

Ahhh good stuff man lol



[Lakota 5,000+ posts]

or he is running a 50 ampre class and is running 20 x 2.5slow blow fuses so he can get some # with the correct fusing
//content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif

No slow blows, they are AGU's. We're not allowed to have slow blows. These fuses are hard to find and they are quite strong for their rating



[skateboardkid 10+ year member]

I have seen the tech before, good job, what class as far as ampres and what Deebee scores on that amperage?

thanks for sharing.



[Lakota 5,000+ posts]

I have seen the tech before, good job, what class as far as ampres and what Deebee scores on that amperage?
thanks for sharing.

My team is running 3kW+ of power on 55A of fusing or less. As far as the current draw, I haven't clamped any of our amps yet. But, I do know of a competitor that is running 6kW of power off of this same setup with 55A of fusing The block in the pictures is from a Blazer that does a 146.5 (should do more soon) in AS2 with a Powerbass 3000 amp @ 0.5 ohm and a hdc315. Keep in mind that score is with the car off, music and a single battery. A 2500.1 and Type R is in there right now and it just did a 146.0 at a show.



[Lakota 5,000+ posts]

Oh yeah, to make the score a bit more impressive, it is at the headrest //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[DDSC 10+ year member]

so headrest is better than dash, guess it makes sense, my car gets louder if I sit up in my seat (I ride reclined a bit)

Is a fuse setup like that harder on your equipment, would you use something like this in a daily??



[Lakota 5,000+ posts]

so headrest is better than dash, guess it makes sense, my car gets louder if I sit up in my seat (I ride reclined a bit)
Is a fuse setup like that harder on your equipment, would you use something like this in a daily??

The headrest is typically the hardest place in the car to meter. There's nothing wrong with using a fuse setup like this for daily. The only thing is that it's better to use these fuses for a show because if you pop all of them it gets expensive. We throw in bigger fuse ratings for daily.



[thefordmccord 10+ year member]

That looks familiar //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif BTW, I'm running 6000 watts through 80 amps of fusing.
