6 x 4ohm speakers on a 2channel (2 Ohms Stereo Stable) amplifier

[Thelivingflesh1]

Hello everyone.
I got a Kenwood Excelon amplifier X621 which is:

• 2 channel and 2 Ohms Stereo Stable / 4 Ohms Mono (Bridged) Stable
• 179 watts RMS x 2 at 4 ohms
• 305 watts RMS x 2 at 2 ohms
• 612 watts RMS x 1 bridged output at 4 ohm

Then i got 6 speakers JVC CS-V527(200Watt max and 27watt rms each) on 4 ohm

Need Help in:

Connecting all 6 speakers to the amplifier in such a way that the amp does not sustain damage & maximum efficiency is achieved

P.S: Dont want to add another amp as there is already one for the sub.

Thanks....Kindly tell me a diagram if possible on how to wire them all.

Click to read more...



[TrQoNTaP69]

Wire in series/parallel for final impedance of 3 ohms .. VC in series & speaker in parallel.



[Popwarhomie 5,000+ posts]

Wire in series/parallel for final impedance of 3 ohms .. VC in series & speaker in parallel.

Almost 2 years late...
