Whats the ohm's on these subwoofers?

[DigitalAudio]

Hey everyone i was just wondering if someone could tell me what ohms my subs are they are digital audio DABP103. I have a pic of them on my avatar. If someone could tell me what ohms they are i'd surely appreciate it, and if so would anyone have a diagram of how to hook the subs together. I took them out and put in truck boxes so now im putting them back in the original box and i have no clue how they get hooked up again.//content.invisioncic.com/y282845/emoticons/crap.gif.7f4dd41e3e9b23fbd170a1ee6f65cecc.gif And one more question are they dual voice coils? Ive read that they are only single but on the subs they have a terminal on each side of it.

Click to read more...



[JAZN 5,000+ posts]

I tried to search for them and some website says 4ohm mono, so my guess is 4ohms but you can verify that if you have a DMM. Your best bet is to wire them in parallel (connect all the +'s together and connect all the -'s together) for a final load of 1.33ohms, assuming your amp can run at that low of an impedance.



[DigitalAudio]

My amp is a Pioneer GM-5100T the specs are 125 Watts x 2, at 4 ohms

• 380 Watts x 1, at 4 ohms BRIDGE

• 75 dBA Signal-to-Noise Ratio (Reference: 1 Watt Output) Its not a very powerful amp but before i tore it all apart it sounded really good. Im assuming my amp cant go down to a 1.33 ohm. what would happen if i hook them up this way View attachment 5346)



[Prowler573 5,000+ posts]

My amp is a Pioneer GM-5100T the specs are 125 Watts x 2, at 4 ohms • 380 Watts x 1, at 4 ohms BRIDGE

• 75 dBA Signal-to-Noise Ratio (Reference: 1 Watt Output) Its not a very powerful amp but before i tore it all apart it sounded really good. Im assuming my amp cant go down to a 1.33 ohm. what would happen if i hook them up this way View attachment 5346)

You can't hook up your subs that way.

That diagram is for a trio of Dual Voice Coil drivers and according to the very limited info I could find on the subs you have they are Single Voice Coil subwoofers.



[lilmaniac2 5,000+ posts]

rant

its not ohms its impedance...

thats the biggest irk ihave... i got some 2 ohms subs so im louder than 4 ohm subs.. no

What impedence are these subs ? would be the correct thing.

/rant



[Prowler573 5,000+ posts]

rant
its not ohms its impedance...

thats the biggest irk ihave... i got some 2 ohms subs so im louder than 4 ohm subs.. no

What impedence are these subs ? would be the correct thing.

/rant

He's trying to find out some info on some gear he's having trouble getting specs on.

Let's not argue semantics, eh?



[DigitalAudio]

can they be single voice when theres terminals on each side of the sub? Theres a positve and negative on each side of the 3 subs.



[Prowler573 5,000+ posts]

can they be single voice when theres terminals on each side of the sub? Theres a positve and negative on each side of the 3 subs.

Meaning there are both positive and negative terminals on each side for a total of 4 terminals per driver?



[DigitalAudio]

yup each one of them looks like this View attachment 5347



[Prowler573 5,000+ posts]

yup each one of them looks like this View attachment 5347

Then I retract my previous statement about that diagram you posted not applying.

I was very much under the impression that you had SVC subs. Apparently I was wrong ~ sorry about that, friend.



[JAZN 5,000+ posts]

Then I retract my previous statement about that diagram you posted not applying.I was very much under the impression that you had SVC subs. Apparently I was wrong ~ sorry about that, friend.

Same here, guess the website I looked at was wrong.

You can wire it the way you posted as long as your amp is stable at that impedance.



[DigitalAudio]

Im just wondering why some of the websites are claiming they are svc when infact they are dvc cuz ive never in my live seen a svc with 4 terminals on it. //content.invisioncic.com/y282845/emoticons/biggrin.gif.d71a5d36fcbab170f2364c9f2e3946cb.gif
