what,do dots terminals on subwoofers mean?

[hondaracer48 10+ year member]

I have a dual2cvr an I wired it up an then I read u want to connect pos. an neg. Term with speaker wire. Well when I did this I didn't think it mattered. My amp has been getting very hott really fast. Wld this have anytjing to do with connecting the wrong terminals. I have a rockford fosgate t500.2

Click to read more...



[Devil Tiger 10+ year member]

Read your subs manual. Specifically says dots on terminal indicate the second voice coil. Also has instructions on how to wire in series/parallel to present the correct ohm load on your amp.

kicker.com/sites/default/files/2007CompVR.pdf



[IonRL205 10+ year member]

I have a dual2cvr an I wired it up an then I read u want to connect pos. an neg. Term with speaker wire. Well when I did this I didn't think it mattered. My amp has been getting very hott really fast. Wld this have anytjing to do with connecting the wrong terminals. I have a rockford fosgate t500.2

It's just kicker's way of showing you which terminals go to which voice coil, most subs just have the terminals 2 to a side, kicker has them spread apart and the 2nd voice coil has the dots so you know which is which.



[VisceralSound 10+ year member]

The "Dots" mean nothing, just to mark the + on one side, and the - on the other. What is your amp wire to?



[IonRL205 10+ year member]

Also that amp isn't 1 ohm stable bridged. The way you have it wired is giving it a load lower than it can handle.

Connect the positive with no dot the negative with a dot and then take your remaining positive and negative and connect it to the amp. (should be positive with a dot and negative with no dot)

You'll be running at 4 ohms bridged so it shouldn't overheat anymore.



[Devil Tiger 10+ year member]

The "Dots" mean nothing, just to mark the + on one side, and the - on the other. What is your amp wire to?

Wrong. The dots do mean something, see above posts. And what is his amp wired to? I would assume subs...



[snoopdan 5,000+ posts]

smh



[Devil Tiger 10+ year member]

smh

Very helpful...fucktard.



[hondaracer48 10+ year member]

I have speaker wire running from a negative to positive terminal(not sure if they are terminals with dots or not) then the left over pos. An neg I have ran to my amp bridged. So doesn't that give me 4ohms bridged? Also my amp is 1ohm stable I think. So would it make sense for my amp to overheat if I have the wrong terminals together?



[IonRL205 10+ year member]

I have speaker wire running from a negative to positive terminal(not sure if they are terminals with dots or not) then the left over pos. An neg I have ran to my amp bridged. So doesn't that give me 4ohms bridged? Also my amp is 1ohm stable I think. So would it make sense for my amp to overheat if I have the wrong terminals together?

Just read my post. Your amp is 1 ohm stable Per channel, not bridged

Just do what my post says and you'll be fine.



[Devil Tiger 10+ year member]

Your amp doesn't support 1-ohm load when it's bridged. Hard to diagnose problem with you "think" you wired it a certain way...



[ThatChevyGuy 5,000+ posts]

Very helpful...fucktard.

Says the man with a tibby and cvr's...



[hondaracer48 10+ year member]

Ok I will do that an hopefully won't burn my amp up. An that is how I wired it, I was saying I think to it being 1 ohm stable. Thanks for help guys



[Devil Tiger 10+ year member]

Says the man with a tibby and cvr's...

So because I drive a tiburon and have cvrs I can't answer a simple question and call you out on trolling? Good one..



[snoopdan 5,000+ posts]

So because I drive a tiburon and have cvrs I can't answer a simple question and call you out on trolling? Good one..

who's trolliing now? douchenozzle.
