WANTED: Blade DSP-2X Servo Programmer Software & information about the "RC-DSP"remote

[SNDZ2GD]

Howdy!

I'm looking for t/Blade DSP-2X Servo Programmer Software for my DSP-2X w/the "new" DSP-2XEM processor.

Unfortunately my old DSP-1 software (ver. 1.36) does not recognize the enhanced 2XEM processor.//content.invisioncic.com/y282845/emoticons/crying.gif.ec0ebefe590df0251476573bc49e46d8.gif

The eprom versions are 1x SVU1R39 & 1x SVU3R39 in my DSP-1 and 1x SVU1R39 & 1x SVU3R40 in t/DSP-2X.

Furthermore I'm looking for information about the slimline "RC-DSP" remote control, especially t/data and/or values of t/2 presets "A" & "B".

Any information WILL BE GR8ly appreciated!

Click to read more...



[SNDZ2GD]

Out of curiosity & frustration I've taken my DSP-2X apart & noticed some very strange/interesting things 2 say t/least!

I was wondering if some of t/DSP-2X owners around here, if any, would like 2 share their insights w/me?

Btw. the "?factory?" seal on my DSP-2X was still intact - anyway here we go:

Here's t/seal on my DSP-2X.

I've also noticed that someone has modified/?hacked? t/parallel port connections.

Furthermore t/resistor "R85" & t/transistor "Q8" are missing and the diode "D3" has been bypassed by a 9,44kOhm resistor.

Detail shot:

??? Can anyone (current or ex-owner, employee or designer/technician) confirm these alterations / modifications ???

Thanx for interest & patience !

//content.invisioncic.com/y282845/emoticons/clap.gif.178cba2c538c68e720c727fcb024b19c.gif

I am looking forward 2 hearing from you soon!



[Rich B 5,000+ posts]

I just ran across this on eBay, dont know if its what you were looking for.

Blade Audio DSP Servo Software

End time: Mar-04-07 20:46:40 PST (5 days 9 hours)

http://cgi.ebay.com/Blade-Audio-DSP-Servo-Software_W0QQitemZ320086838729QQihZ011QQcategoryZ14931QQssPageNameZWDVWQQrdZ1QQcmdZViewItem



[SNDZ2GD]

Hello "Rich B",

thanx 4 t/link!

That was t/one, but I was fortunate enough 2 get it 4 free from a cs&p-Forums member ! //content.invisioncic.com/y282845/emoticons/biggrin.gif.d71a5d36fcbab170f2364c9f2e3946cb.gif

I can now confirm that t/DSP-2X is supposed 2 l@@k like this on t/inside.

DSP-2X: Modified parallel port/solder side (2 traces cut & 2 new connections)

DSP-2X: Modified circuit board/component side (transistor "Q8" & resistor "R85" missing, "D3" w/bypass resistor)

It was only a matter of t/right software version (DSPDOS rev.2.00 & upwards).

Special THANX 2 "tristan20" from t/car sound & performance-Forums 4 providing me with t/correct software! //content.invisioncic.com/y282845/emoticons/clap.gif.178cba2c538c68e720c727fcb024b19c.gif

Honorable mention:

"robmar", also from cs&p-Forums. Thanx 4 Software & Links! //content.invisioncic.com/y282845/emoticons/bigwave.gif.16324171cad2db62cf4f16568b038478.gif

..., but I'm still looking for information about BLADE's RC-DSP remote!

//content.invisioncic.com/y282845/emoticons/idea.gif.5acb6a39a9b92425414c316dda202bad.gif

Anyone?



[Kriszilla 10+ year member]

Sometimes manufacturers will find a bug and need to make a change, or will simply design a board that has more features than needed. It's easier to just leave off components in the latter case, and do bypass/re-circuit work in the former case, than to redesign the entire circuit board.
