So Iopened my amp up....GUTS

[btdickey99 5,000+ posts]

Well I got a little bored and decided to open my amp up and take pics of the guts....the amp is Zenon 7501 2200@1

Discuss

Click to read more...



[silvercookie 5,000+ posts]

shitt camera



[btdickey99 5,000+ posts]

shitt camera

yea my gf has mine...//content.invisioncic.com/y282845/emoticons/crap.gif.7f4dd41e3e9b23fbd170a1ee6f65cecc.gif

should I list out the component numbers to help?



[dragnix 5,000+ posts]

you got this from 02parkave?



[btdickey99 5,000+ posts]

you got this from 02parkave?

well tapout who got it from 02parkave....my main reason for opening it up was to find out the amperage...which I do not see:crap:



[dillinja666 10+ year member]

hey its my amps twin brother! i got mine from 02parkave also..



[dragnix 5,000+ posts]

well tapout who got it from 02parkave....my main reason for opening it up was to find out the amperage...which I do not see:crap:

hey its my amps twin brother! i got mine from 02parkdave also..

yea well i should be getting the other two soon. And I already have one right now with the same board. So...I'm better than you both //content.invisioncic.com/y282845/emoticons/tongue.gif.6130eb82179565f6db8d26d6001dcd24.gif



[btdickey99 5,000+ posts]

hey its my amps twin brother! i got mine from 02parkave also..

yea well i should be getting the other two soon. And I already have one right now with the same board. So...I'm better than you both //content.invisioncic.com/y282845/emoticons/tongue.gif.6130eb82179565f6db8d26d6001dcd24.gif

either of you know the amperage of this....no fuses unless I am missing something



[dragnix 5,000+ posts]

either of you know the amperage of this....no fuses unless I am missing something

Manufacturer's recommendation is a 200amps fuse. So you're looking somewhere in that area



[btdickey99 5,000+ posts]

Manufacturer's recommendation is a 200amps fuse. So you're looking somewhere in that area

that means I will move up a class for NSPL:crap:



[btdickey99 5,000+ posts]

I wonder if I could get away with 150a



[dragnix 5,000+ posts]

for the comp or for the amp? You can try for the amp, but I wouldn't recommend it if you're competing



[dragnix 5,000+ posts]

I have 150a with mine, but mine's a daily setup



[btdickey99 5,000+ posts]

I have 150a with mine, but mine's a daily setup

I want to for a comp, so that I am able to compete in the 150a class....what risk would I run into?



[dragnix 5,000+ posts]

I want to for a comp, so that I am able to compete in the 150a class....what risk would I run into?

Basically you might run your amp to where it would pull more than 150amps. Which, would be over current and burn the fuse. That's why I said for daily it's ok, because it won't be likely you'll pull that much current. But since it's a comp, it might be possible.
