old school rockford amp

[bmk6795 10+ year member]

i found an oldschool rockford 4channel on cl, wondering if it's worth picking up. really want toknow the specs on it if anyone recognizes it, any input is appreciated.

Click to read more...



[Jes 42 10+ year member]

Looks like the 2 ch..



[pro-rabbit 5,000+ posts]

Not really old school. Also not really all that great to be total honest.

And no, that is not a 4 channel amplifier, it is a 2 channel as already stated.



[bmk6795 10+ year member]

Not really old school. Also not really all that great to be total honest.
And no, that is not a 4 channel amplifier, it is a 2 channel as already stated.

ah yeah it's a 2ch. didn't really look at it, just read the description. Thanks for the input man.



[Jes 42 10+ year member]

Does it say 201s on the rf logo?



[bmk6795 10+ year member]

Does it say 201s on the rf logo?

honestly I'm not sure, if it does what's it mean?



[bmk6795 10+ year member]

Does it say 201s on the rf logo?

yeah it says 201s



[Jes 42 10+ year member]

yeah it says 201s

50 watts RMS x 2 at 4 ohms

100 watts RMS x 2 at 2 ohms

200 watts RMS x 1 bridged output at 4 ohms

stereo or bridged mono output

4-ohm stable in bridged mode

Tri-way capable (Tri-Way crossover required)

requires 10-gauge power and ground leads — wiring and hardware not included with amplifier

120 Hz high-pass, 80 Hz low-pass crossovers (12 dB/octave)

MOSFET power supply and output devices

MEHSA mounting technology increases the heat transfer from the MOSFET output devices to the heat sink, for higher power output, lower operating temperatures, and greater reliability

TOPAZ — noise-killing differential inputs that eliminate 80% of ground loop noise

*****•ana circuitry keeps preamp voltages low and signal paths simple for outstanding audio quality

NOMAD — advanced protection circuitry for "intelligent" shutdown protection

selectable Punch Bass (0/6/12 dB boost at 45 Hz)

speaker- and preamp-level inputs

10-1/8"W x 2-7/16"H x 9-7/8"D



[bmk6795 10+ year member]

50 watts RMS x 2 at 4 ohms100 watts RMS x 2 at 2 ohms

200 watts RMS x 1 bridged output at 4 ohms

stereo or bridged mono output

4-ohm stable in bridged mode

Tri-way capable (Tri-Way crossover required)

requires 10-gauge power and ground leads — wiring and hardware not included with amplifier

120 Hz high-pass, 80 Hz low-pass crossovers (12 dB/octave)

MOSFET power supply and output devices

MEHSA mounting technology increases the heat transfer from the MOSFET output devices to the heat sink, for higher power output, lower operating temperatures, and greater reliability

TOPAZ — noise-killing differential inputs that eliminate 80% of ground loop noise

*****•ana circuitry keeps preamp voltages low and signal paths simple for outstanding audio quality

NOMAD — advanced protection circuitry for "intelligent" shutdown protection

selectable Punch Bass (0/6/12 dB boost at 45 Hz)

speaker- and preamp-level inputs

10-1/8"W x 2-7/16"H x 9-7/8"D

you think it's worth 50 bucks?



[Jes 42 10+ year member]

you think it's worth 50 bucks?

Thats what i paid for the 301s i had.I'd try 40.00 Good to use for tweets or small comps.
