need a box drawn up if there are any takers
subs:
(2) RE SE D4's - 10"
amp:
us amps MD1
width can be no wider than 32"
height can be no taller than 16"
no limit to the depth
would like it tuned to 34hz
t/s specs are:
Electrical Q Value -Qes: 0.46
Mechanical Q Value -Qms: 4.4
Total Speaker Q Value -Qts: 0.42
Free Air Resonance -Fs: 26.6 Hz
Equivalent Compliance -Vas: 31 liters
One-Way, Linear Excursion -Xmax: 18 mm
Efficiency -SPL 1W/1m: 83.2 dB SPL
Effective Piston Area -Sd: 310 cm^2
DC Resistance -Re: 2.8 ohm
Nominal Impedance -Znom: Dual 2/4 ohm
Thermal Power Handling -Pe: 600 W
Force Factor -Bl: 17.7
Mounting Depth - 6.4"
Mounting Hole Diameter - 9.3"
Overall Diameter - 11"
Bolt Hole Circle - 10.1"
Motor Width - 7.3"
Motor Depth - 3.4"
Basket Depth - 2.94"
Displacement - 0.14 cu. ft.
Weight - 21 lbs.
going in this:
subs:
(2) RE SE D4's - 10"
amp:
us amps MD1
width can be no wider than 32"
height can be no taller than 16"
no limit to the depth
would like it tuned to 34hz
t/s specs are:
Electrical Q Value -Qes: 0.46
Mechanical Q Value -Qms: 4.4
Total Speaker Q Value -Qts: 0.42
Free Air Resonance -Fs: 26.6 Hz
Equivalent Compliance -Vas: 31 liters
One-Way, Linear Excursion -Xmax: 18 mm
Efficiency -SPL 1W/1m: 83.2 dB SPL
Effective Piston Area -Sd: 310 cm^2
DC Resistance -Re: 2.8 ohm
Nominal Impedance -Znom: Dual 2/4 ohm
Thermal Power Handling -Pe: 600 W
Force Factor -Bl: 17.7
Mounting Depth - 6.4"
Mounting Hole Diameter - 9.3"
Overall Diameter - 11"
Bolt Hole Circle - 10.1"
Motor Width - 7.3"
Motor Depth - 3.4"
Basket Depth - 2.94"
Displacement - 0.14 cu. ft.
Weight - 21 lbs.
going in this:
