Sold ID OEM mid drivers $90 shipped

[hessdawg 10+ year member]

hello i am new to this board but i have sold some of these over on eca and diy . These are OEM Image Dynamics mid/midbass drivers. very similar in sound and looks to a cx64. they are 4 ohm will take 150-175 watts with nice detail and extreme impact.

zukiaudio, gentlejax2,and tristan20 have bought these and enjoyed them.

marv was impressed with the impact playing 1 for sub duty in a .20 cu ft box.

I think we are gonna build a 8in cubed box for 4 of these and see how it sounds.

Very beefy and well built each speaker weighs about 5 lbs. shipping is on me though.

$90 shipped //content.invisioncic.com/y282845/emoticons/veryhappy.gif.fec4fed33b4a1279cf10bdd45a039dae.gif

Click to read more...



[hessdawg 10+ year member]

the v2's next to the orig oems nest to a smaller prototype



[hessdawg 10+ year member]



[hessdawg 10+ year member]



[hessdawg 10+ year member]

specs



[hessdawg 10+ year member]

* Loudspeaker Enclosure Analysis Program

* LEAP® EnclosureShop 5.1.0.334 Jan/25/2005

* ©1993-2003 LinearX Systems Inc

* Date: Mar 4, 2009 Wed 3:20 pm

* LTD File=C:\Program Files\LEAP\Transducers\OEM 2.0

* Electro Mechanical Parameters

Name= QT 6.0 soft spider, fp41mm

Note= 8-20-07

Model= TSL

Domain= FreeAir

Shape= Round

Profile= Cone

Fmd= 3.0000 KA

Qmd= 1.0000

Flp= 8.0000 KA

Qlp= 2.0000

Znom= 3.2000 Ohm

Revc= 3.2000 Ohm

Sd= 12.9000E-3 M²

Mmd= 24.9610E-3 Kg

Pmax= 150.0000 W

Rtvc= 2.5000 °C/W

Xgap= 8.0000E-3 M

Xcoil= 18.0000E-3 M

Xmax= 5.0000E-3 M

Krm= 2.6740E-3 Ohm

Erm= 830.0000E-3

Kxm= 20.0600E-3 H

Exm= 593.0000E-3

Rms= 1.8061 N·S/M

Mms= 25.8030E-3 Kg

Cms= 439.7697E-6 M/N

Vas= 10.4526E-3 M³

Fo= 47.2468 Hz

Qms= 4.2412

Qes= 0.5580

Qts= 0.4931

BL= 6.6277 T·M

Levc= 570.7839E-6 H

SPLo= 85.7920 dB

No= 189.4000E-3 %

* End



[Shinju 10+ year member]

Very nice.

don't suppose you have any of the Versions left that you were selling by chance?



[rollerdj 10+ year member]

how many of these do you have? interested in any trades for 2 pair?



[Cravingbass123]

interested in a pair

wish they had those phase plugs on the cone though!



[jonny101abc 10+ year member]

I'll take 2pairs of the V.2. When u get them in!

Those new motors look sweet as hell, like mini RD HW's

John



[rollerdj 10+ year member]

i want two pairs of the V1's. still have a few?



[riddla 10+ year member]

this justs gets better n better. Great guy to deal with. I live in the UK and Hessdawg sent me some id oems swift delivery. Great speakers I have to say and beefy to f**k. Think ima have to get some of these new ones once there ready. THUMBS UP ?)



[maloy013 10+ year member]

those are nice still the same price?//content.invisioncic.com/y282845/emoticons/biggrin.gif.d71a5d36fcbab170f2364c9f2e3946cb.gif



[hornedfrog1985 5,000+ posts]

Wake up I sent you a pm guy.



[hessdawg 10+ year member]

i hope to have some for sale in the next 2 weeks

these as they are now would be available in 2 and 4 ohm and be in the $120 -130 range shipped

i am also thinking about another carbon cone to rase the spl back to 90db but carbon is much more expensive now and the same driver with a carbon cone will me in the $160 shipped.

here are the specs on the smaller 6.5 inch to the right these wouls be in the $80 range shipped

* Loudspeaker Enclosure Analysis Program

* LEAP® EnclosureShop 5.1.0.334 Jan/25/2005

* ©1993-2003 LinearX Systems Inc

* Date: Feb 24, 2009 Tue 4:03 pm

* LTD File=C:\Program Files\LEAP\Transducers\baby oem

* Electro Mechanical Parameters

Name= baby oem

Note=

Model= TSL

Domain= FreeAir

Shape= Round

Profile= Cone

Fmd= 3.0000 KA

Qmd= 1.0000

Flp= 8.0000 KA

Qlp= 2.0000

Znom= 3.6000 Ohm

Revc= 3.6000 Ohm

Sd= 12.5000E-3 M²

Mmd= 14.5000E-3 Kg

Pmax= 100.0000 W

Rtvc= 2.5000 °C/W

Xgap= 6.0000E-3 M

Xcoil= 16.0000E-3 M

Xmax= 5.0000E-3 M

Krm= 759.1800E-6 Ohm

Erm= 856.0000E-3

Kxm= 15.0100E-3 H

Exm= 578.0000E-3

Rms= 3.7550 N·S/M

Mms= 15.3031E-3 Kg

Cms= 164.9985E-6 M/N

Vas= 3.6823E-3 M³

Fo= 100.1591 Hz

Qms= 2.5647

Qes= 0.8362

Qts= 0.6306

BL= 6.4390 T·M

Levc= 374.5836E-6 H

SPLo= 88.2939 dB

No= 424.2000E-3 %

* End



[SWFL 10+ year member]

could i use a set of these to go passive with the cdt 480 xover and tw-25 tweets for power i got a zx850.4



[hessdawg 10+ year member]

do you happen to know the x over points of the cdt ????



[Xprime4 10+ year member]

do you happen to know the x over points of the cdt ????

4.3khz from what i remember. don't know what slope tough

hessdawg, how those mids compare to those coming off the ctx65cs? are they more sensitive?



[Xprime4 10+ year member]

lil bump on id oem vs ctx65cs mids



[hessdawg 10+ year member]

i haven't heard the ctx65cs mids if any body has please chime in

update

called to get some production speakers and was told about a new oem 2.5 that will be different than these 2.0 prototypes. the 2.5 should be cheaper ($90), more efficient(91db), and handle more power (200w) the only trade off would be freq response starts falling off @ 2500k. i should have these new 2.5s in next week. so i'm gonna hold off on the 2.0's for right now.

please post your thoughts on what you want

the 2.0's on this page $130 shipped,150watt rms, 85db efficient, freq response 47-5k

or 2.5's $90 shipped, 200 watts rms, 91 db efficient,freq response 47-2.5k



[SRim23 5,000+ posts]

in about a month ill have a bunch of money coming in ..... probably pick up some of the 2.5's in a month or so if you got em.

be ok off of 150rms you think?
