How many bends in a port is to many?

[LosIsATool 5,000+ posts]

Is 3 OK?

Click to read more...



[LosIsATool 5,000+ posts]

Bump for a easy question



[wenn_du_weinst 10+ year member]

if you have constant width and ample port area then you will be fine with 50 bends.



[Bettr n' Revrse 5,000+ posts]

Yep



[LosIsATool 5,000+ posts]

Thanks guys.. My headache is over



[wenn_du_weinst 10+ year member]

see //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[LosIsATool 5,000+ posts]

see //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif

Ive seen a lot but that dont mean it worked.lol



[wenn_du_weinst 10+ year member]

that worked it's a horn, just trying to show a design with multiple bends with 45's that make sure the port stays constant in the bends.



[kmanian 5,000+ posts]

if you have constant width and ample port area then you will be fine with 50 bends.

I disagree, for all reasonable installations 360 degrees of bends are pretty much the max before you run into issues.

0.02



[LosIsATool 5,000+ posts]

Ill be going across the bottom, up the back, and out the back.



[kmanian 5,000+ posts]

I dont see any issues there



[Moble Enclosurs 10+ year member]

3 can be ok, but may not always fit the application. The good news is, with 3 bends, the amount of response change that occurs can be inaudible if the bends are acute. The main thing to watch for is out of phase response band....which is why many bends are a concern. The more you use, the more resonances can occur in the response, and the less smooth the output and phase can become more sensitive.

So, minimizing the amount of bends is usually a great idea unless you know how to personally account for them in the design, which I can guarantee not many people in the field can do accurately.
