Box Build for Twista89

[DNick454 10+ year member]

Just a simple single-chambered ported box for Twista89. My apologies for the crappy looking pictures and background. I built the box in my basement since it's been rainy the past several days. Believe me, I don't like it any more than you do, especially the dust. I literally blew sawdust out of my nose, was pretty funny/gross:crazy:

Anyways, the build is 3.55 cubic feet (net) including port and sub displacement. This will be housing (2) Alpine Type R D4's. The port is 51 sq. in and is tuned to 35Hz with subs in box.

Outer box dimensions are 38" x 16" x 16"

Buyer requested a raw MDF enclosure but we decided upon painting the port to match the Type R logo to at least make it look somewhat appealing //content.invisioncic.com/y282845/emoticons/laugh.gif.48439b2acf2cfca21620f01e7f77d1e4.gif

The port exit is also flared with a 3/8ths inch round-over. Here's some pics of teh buildz.//content.invisioncic.com/y282845/emoticons/wink.gif.608e3ea05f1a9f98611af0861652f8fb.gif

Purty cuts

Box back and sides up, screwed, and glued

Pre-painting the port walls

Port Assembled

Moar pix in progress

Click to read more...



[DNick454 10+ year member]

MOAR PIX!

Front Baffle in place

NEW TOYZ! Thanks Mazdakid!

Ran to Menards and picked this up, 33 bucks but meh... I needed it

Why you DON'T use shitty router bits

1st pass with beefy router bit //content.invisioncic.com/y282845/emoticons/biggrin.gif.d71a5d36fcbab170f2364c9f2e3946cb.gif

Finished front baffle

Moar pix uploading //content.invisioncic.com/y282845/emoticons/crazy.gif.c13912c32de98515d3142759a824dae7.gif



[SELFMADE]

Haha nice Ya its always good to invest in good router bits



[DNick454 10+ year member]

Box with top on it

Hit the port edge with the round-over bit and then re-painted it a tad.

Finished product, just needs a flush-cut router along the edges of the box so it's all even and then a finish sanding. (sorry for the weird bubbles, I think some dust got on the camera)

Let's figure out a time and place as to when you can pick it up Twista.

Another build log coming soon for another local, a friend, and if I ever get time, a small 6th order bandpass for my home stereo in the house //content.invisioncic.com/y282845/emoticons/biggrin.gif.d71a5d36fcbab170f2364c9f2e3946cb.gif



[SELFMADE]

No double baffle? or Flush moun? lol just messin.. Nice box man..



[DB-Audio 10+ year member]

looks great great job



[DNick454 10+ year member]

No double baffle? or Flush moun? lol just messin.. Nice box man..

Originally, a flush-mount double baffled front was the plan. But due to dimension constraints and nothing too high powered, the idea was scraped to achieve a little more internal volume.

The original design was 3.2 cubes @ 35. With the double baffle taken out, it freed up some volume and lowered the tuning, so I shortened the port and freed up a bit more volume, so it's now 3.55 cubes.



[DonH 5,000+ posts]

the side opposite of the port...... reason for the overhang? u gona trim that?



[DonH 5,000+ posts]

the side opposite of the port...... reason for the overhang? u gona trim that?

other than that looks great!



[DNick454 10+ year member]

the side opposite of the port...... reason for the overhang? u gona trim that?

Yeah, the box is 99% done, I purposely made the front baffle a tad long. I like to have pieces be a little longer. You can always trim off, you can't add back on. If the piece comes short of the adjacent panel, it looks shitty as hell, so I like to have a bit of overhang when I build it, then hit it with a sander or in this case, since I've got the router now, a flush-cut bit and then I'll sand all sides and get rid of any glue residue on the outside and add the terminal cups. Structurally though, the box is finished.



[Twista89 10+ year member]

Box looks great man...I needed a box more for functionality than looks and nick did a great job with the plans. Cant wait to get rid of this sealed prefab crap....



[MasterOfAllBass 10+ year member]

i like it. what kind of paint did u use? Did u prime?



[DNick454 10+ year member]

i like it. what kind of paint did u use? Did u prime?

I used some Ace Hardware brand primer then some red enamel spray paint. I just took my time and tried to at least mask it somewhat nicely since the box would be in raw wood form... it would look ghey if there were paint splotches all over it.
