Alt for 13,000 watts

[metalheadjoe 10+ year member]

Yeah, I missed that. It's a really simple way to get to that answer too, and I was surprised nobody up to that point said how. OP (and everyone else who finds this), can get there with whatever they want to figure out now.

Many on this site are capable of math, but don't think math outweighs experience.



[GambellaDiddler]

Personally I wouldn't take even over mojo

Really? Why? Just curious.



[GambellaDiddler]

If you wanted to just get as loud as you can you might consider just buying some shitbox van or large SUV you don't care about and doing a flat wall. You'd get louder with more space, you won't be destroying your nice vehicle, and much of the gear you buy can be put into another vehicle down the road.

Well I’m going to be listening at a reasonable level while driving but want the potential of getting loud if I want to.



[KicktheSDbasshead]

Really? Why? Just curious.

I think in equal enclosures it sounds better



[GambellaDiddler]

I think one of you is guessing.

For an alternator
13,000 watts / 14.4v = 902 amps.
You need to know your amps efficiency which you would divide by. If your amp is 85% efficient,
902 / .85 = 1064 amps Thats 1064 amps ON TOP of what your vehicle needs without the stereo. If the factory was 220 amps, then plan for about 1300. Did I see you can get a 320amp alt, then get 4 of those.

Not sure about your amp if that was peak, or RMS. Not sure of if you are planning for peak or what kind of music, or other variables. You can do caps, and cut back. There are just some details missing to figure out the best option.

For a battery, 13,000 watts / 12 volts (if you plan on listening to this at that level with the engine off) = 1083 amps. Then again divided by (point percentage). If 85% then 1083/ .85 = 1274 amps. I don't know AGM batteries, but I think its somewhere around 300-400amps discharge. Which would mean you would need to plan for 3-4 alternators, and 3 batteries if you plan on driving it. Four or more batteries if you want to listen to it while the engine is off. (I would plan for four alts, and then caps if you are getting voltage dropping at hits. Just because I'm betting you're going to have to buy a alt bracket that costs about half the price of a fourth alt. Not something I would want to buy a 3 alt bracket, belt, and then start adding caps, when you could buy a 4 alt bracket in the first place).

So I like metal with lots of bass and rap.
with rap I like lows. With metal I like a hard hit. ( pounding)

amp: I like the crescendo bc 6k. Not sure on the efficiency level.

I’d be Listening while thinking the car. ( driving around etc )



[GambellaDiddler]

I think in equal enclosures it sounds better

So the mojos I have are old. Atleast 15years.



[KicktheSDbasshead]

So the mojos I have are old. Atleast 15years.

Only a testament to their durability evl won't last that long id wait until the mojos gave up then go evl honestly and trust me unlike 99.5 of the people on here I am a skar fan lmao



[SilverSquared 10+ year member]

I have a 2015 GC SRT that I am working on a sound system in. Certainly NOT the easiest vehicle I've ever dealt with. I bought a newer head unit with apple car play and android auto. All it does is power cycle. I was told there's something I need to turn on in the pcm/ecu. So..I bought AlfaOBD to do that...but dont know what to do after that. So....started buying the system. I think it'll be funny when done. I'll start a build thread when I start the install on it all.



[maylar 10+ year member]

For an alternator
13,000 watts / 14.4v = 902 amps.

It's also worthy to note that 13 KW translates to about 17 HP worth of mechanical power to drive those alternators



[Old_Slapper]

If your goal is to do nothing else but shake the ground, go with bigger subs. At the very least, 18". To shake the ground, you need depth, and bigger subs hit the deeper tones better. You can bring in sound quality by adding 10's or 12's. If you want to build pressure in your Jeep to make your girls hair go crazy, get 18" subs with extremely high excursion.

Running 13k watts at full tilt will literally make you deaf within a minute. So, I doubt you will use the entire 13k for more than a 10 second burst. I would say 700 amps of alternator power and a huge 1,300 ah size power bank would suffice for your needs. Really, though, you could probably get away with only an 800 ah power bank.
