12" Eclipse SW8200

[bumpin buick 5,000+ posts]

Item(s) for Sale:

1. Product:

12" Eclipse SW8200 (TC based)

Item(s) Description/Condition:

Been sitting at an eclipse dealer shop for 5-6 years in the back with a bunch of other old gear, the guy called me and said it may be something id be interested in. LMS coil, copper shorting ring on ID of slugs, removable baskets, 9.75" spider.

38mm xmax

Price:

$200+ shipping

Shipping and Miscellaneous Item Information:

--- mechanical ---

Fs 22.792E+00 Hz Free air resonance

Qms 4.262E+00 Q mechanical

Vas 81.385E-03 m^3 Suspension compliance

Cms 223.135E-06 m/N 1/(suspension stiffness)

Mms 218.523E-03 kg Moving mass

Rms 7.343E+00 kg/s Mechanical resistance

Xmax ** 0.000E+00 m Maximum acoustic linear motion

Xmech** 0.000E+00 m Mechanical displacement

Dia 254.000E-03 m Piston diameter

Sd 50.671E-03 m^2 Piston area

Vd ** 0.000E+00 m^3 Displacement volume

--- electrical ---

Qes 770.670E-03 Q electrical

Re 2.855E+00 ohms Voice coil DC resistance

Le 1.062E-03 Henries Inductance @1 kHz

Z 8.971E+00 ohms Impedance @1 kHz

BL 10.766E+00 Tm Motor force - Newtons/Amp

Pe ** 0.000E+00 W Max Electrical Power

--- electro-mechanical ---

Qts 652.644E-03 Q total

no 117.488E-03 % 1/2-space ref efficiency @ 1m/1W

1-W SPL 82.718E+00 dB sensitivity at 1m on-axis

2.83V SPL 87.193E+00 dB sensitivity at 1m on-axis

--- motor constants ---

Krm 13.063E-03 ohms constant resistive motor impedance

Erm 659.072E-03 exponent resistive motor impedance

Kxm 16.241E-03 Henries constant reactive motor impedance

Exm 707.456E-03 exponent reactive motor impedance

Item Pictures:

(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).

Click to read more...



[audio_phill 10+ year member]

trades?



[audio_phill 10+ year member]

Pics of cone too?



[bumpin buick 5,000+ posts]

trades?

Let me know you were thinking, cash is always king and to be honest thats what I need to pay for the steel to make what I want.

Pics of cone too?

I apologize it has some smudges and dust, all can obviously be whipped clean with some windex.



[audio_phill 10+ year member]

TC7 top-plated TC9 full copper motor and $120? standard 6 x 5" BP

Epic Proto 8 and $80



[bumpin buick 5,000+ posts]

this is phils now



[resko1 10+ year member]

TC7 top-plated TC9 full copper motor and $120? standard 6 x 5" BP
Epic Proto 8 and $80

Phil... I wanted those motors.

And BTW Matt, where did you get TSP's like that?



[bumpin buick 5,000+ posts]

Phil... I wanted those motors.
And BTW Matt, where did you get TSP's like that?

guy pulled em on diyma with his software and gave em to me. havent used the new praxis pod yet //content.invisioncic.com/y282845/emoticons/frown.gif.a3531fa0534503350665a1e957861287.gif



[audio_phill 10+ year member]

Phil... I wanted those motors.

used one to snag a sw8K, paid cash for this after selling a proto 12, I will have 5 now, i thought we were going straight cash for the lmt 12, ugh... misunderstood, I was planning on $330 plus shipping for it //content.invisioncic.com/y282845/emoticons/frown.gif.a3531fa0534503350665a1e957861287.gif



[audio_phill 10+ year member]

NVM Wrong TSP's posted in this reply look below lol.



[audio_phill 10+ year member]

Copied wrong specs wrong place lol, SW8200 TSP's from this driver

Re = 3.2856 ohms

Fs = 22.0150 Hz

Zmax = 23.5699 ohms

Qes = 0.9382

Qms = 5.7920

Qts = 0.8074

Le = 1.0685 mH (at 1 kHz)

Diam = 256.5400 mm ( 10.1000 in )

Sd =51689.2299 mm^2( 80.1185 in^2)

Vas = 87.1135 L ( 3.0764 ft^3)

BL = 10.5028 N/A

Mms = 227.7101 g

Cms = 229.5200 uM/N

Kms = 4356.9180 N/M

Rms = 5.4381 R mechanical

Efficiency = 0.0931 %

Sensitivity= 81.7071 dB @1W/1m

Nice lol.



[resko1 10+ year member]

used one to snag a sw8K, paid cash for this after selling a proto 12, I will have 5 now, i thought we were going straight cash for the lmt 12, ugh... misunderstood, I was planning on $330 plus shipping for it //content.invisioncic.com/y282845/emoticons/frown.gif.a3531fa0534503350665a1e957861287.gif

Its cool. Im working on it now. Have some special cones on the way for you

And thanks for the tsp's!



[audio_phill 10+ year member]

lol, NP, you're welcome, special cones you say... very interesting lol.



[smarkwilson]

Do you still have the subwoofer and what is the lowest you will take plus shipping ?
