Ti-LMS?

[pro-rabbit 5,000+ posts]

Here specsEclipse SW9152 - 15" Subwoofers - Sonic Electronix

I do not agree with those specs



[Liquid Bass 10+ year member]

I do not agree with those specs

yea thats what im reading. most ppl say this sub should take WAYYYY more power and a lot more cubes



[RAM_Designs 5,000+ posts]

3.75ft^3 at 30hz.



[ciaonzo 5,000+ posts]

Holy fuck ballz. So many wrong answers in this thread.

OP please post a pic of your exact drivers so we can put an end to this awful spreading of misinformation. I will tell you exactly what you have.

The drivers pictured in post #3 are very rare LMS protos and have nothing in common to the Ti's. Every single part on that driver is different from the Ti except the basket and the T-yoke.



[Liquid Bass 10+ year member]

those are the exact subs i have



[Liquid Bass 10+ year member]

these are the LMS subs i am referring to. they seem to be the same as the eclipse

TC Sounds LMS Ultra 5400 18" DVC Subwoofer | Parts-Express.com



[ciaonzo 5,000+ posts]

Bro, you don't have a clue what you're talking about and that's okay. We're here to help.

Take a look in this link below and reconsider what you've said about your Ti or Ti Pro being the same. The Ultra you provided a link to is even further away from your Ti's, lol. There's more than meets the eye. That's why I want you to point YOUR camera at YOUR drivers so I can see exactly what YOU have.

FS: TC Sounds Linear Motor Prototypes



[RAM_Designs 5,000+ posts]

these are the LMS subs i am referring to. they seem to be the same as the eclipseTC Sounds LMS Ultra 5400 18" DVC Subwoofer | Parts-Express.com

That's a 4hp motor like the Ti Pro used(they might not be exactly the same though). The motor on the regular Ti is (one of)the 3hp motor.



[ciaonzo 5,000+ posts]

That's a 4hp motor like the Ti Pro used(they might not be exactly the same though). The motor on the regular Ti is (one of)the 3hp motor.

Yep, 4HP but the Ultra has four .75" slugs with a short top plate and the 5200/Ti Pro has three .75" slugs with a tall top plate. Makes a big difference in flux geometry and response linearity. //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[RAM_Designs 5,000+ posts]

Yep, 4HP but the Ultra has four .75" slugs with a short top plate and the 5200/Ti Pro has three .75" slugs with a tall top plate. Makes a big difference in flux geometry and response linearity. //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif

I had a Ti PRO once...messed up and sold it. //content.invisioncic.com/y282845/emoticons/crap.gif.7f4dd41e3e9b23fbd170a1ee6f65cecc.gif



[ciaonzo 5,000+ posts]

I had a Ti PRO once...messed up and sold it. //content.invisioncic.com/y282845/emoticons/crap.gif.7f4dd41e3e9b23fbd170a1ee6f65cecc.gif

She was a high inductance beast anyhow. Probably pretty fun, though!



[audio_phill 10+ year member]

I do not agree with those specs

yea thats what im reading. most ppl say this sub should take WAYYYY more power and a lot more cubes

I have a thread listing actual pulled TSP's and recommended boxes for all three sizes of 9000 series Ti's.

3.75ft^3 at 30hz.

lol, a lil cramped and huge gains above tuning, but okay for entry level build

That's a 4hp motor like the Ti Pro used(they might not be exactly the same though). The motor on the regular Ti is (one of)the 3hp motor.

Wonder why it went from TC4LM to standard TC4HP when the 5200 was the original 4HP??

Yep, 4HP but the Ultra has four .75" slugs with a short top plate and the 5200/Ti Pro has three .75" slugs with a tall top plate. Makes a big difference in flux geometry and response linearity. //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif

Ahhh, lovin the technicals big //content.invisioncic.com/y282845/emoticons/thumbsup.gif.3287b36ca96645a13a43aff531f37f02.gif



[DarkScorpion 10+ year member]

So let's lay it out:

You most likely have a standard Eclipse Ti sub, not the Ti Pro.

Standard Eclipse Ti: 3hp motor, 3" coil, ~1500w RMS. TSPs can be found from Audio_Phill (they are on CACO)

Eclipse Ti Pro: 4hp motor, gobs of power, most definitely not in your possession.

The easiest was to tell the difference is if the motor is f*cking massive and the sub has a 4" coil (Ti Pro). Also, the Ti Pro was never sold under 15".



[Liquid Bass 10+ year member]

Bro, you don't have a clue what you're talking about and that's okay. We're here to help.
Take a look in this link below and reconsider what you've said about your Ti or Ti Pro being the same. The Ultra you provided a link to is even further away from your Ti's, lol. There's more than meets the eye. That's why I want you to point YOUR camera at YOUR drivers so I can see exactly what YOU have.

FS: TC Sounds Linear Motor Prototypes

i realize they are not the same i was just showing you what i was talking about earlier. now that the original question has been cleared up i just need some specs for a box build. i just need to know how many cubes you guys think i should put this is ported. i want it LOW.

BTW thanks for your help so far



[audio_phill 10+ year member]

4HP motor on my 12
