Class D mono amplifier, all MOSFET design
Dynamic Power Rating: 1200 watts RMS
Rated Power @ 4 ohm (RMS): 425 x 1
Rated Power @ 2 ohm (RMS): 725 x 1
Rated Power @ 1 ohm (RMS): 1200 x 1
Frequency response: 20Hz - 300Hz
Crossover range/scope: LP 30 - 250hz, 12/24 db octave
Input sensitivity: 200mV - 5V
Equalization Circuit: Intelli Q 10 db
Dimensions*: 18.7"L x 10.5"W x 2.3"H (* Amplifier dimensions are for heat sink only; add 2 1/2 inches per side to allow for end cap installation )
Protection: - Thermal protection, DC offset protection, Reverse polarity protection, Short circuit protection, Over/under voltage protection
Class D mono block model features:
Selectable 12/24 dB/octave variable low-pass filter
Intelli Q bass optimization circuit and remote gain option
Separately adjustable, selectable variable high-pass filter with proprietary Copy/Master control circuit for RCA outputs
Copy/Master feature supports gain and crossover adjustment matching in multiple amp
Switchable phase invert function
Heavy gauge direct-wire high current satin finish power and speaker terminals
Product Description
The 1200D delivers an astounding 1200 watts RMS into 1 ohm - and those are real, 13.8V continuous watts, not the "if lighting strikes" watts some companies claim. Whether your goal is an SPL world record, or you just want the meanest, hardest hitting system in town, these four class D models will get the job done. Extreme power, extreme efficiency, and extreme construction details like massive paralleled internal busses and a directed internal air flow cooling design characterize these monster amps that proudly advance Orion's legacy.
