I have had these since 1998 I used them active for about 2 years then took them out. They have been sitting in my basement ever since. Some how I lost the Crossovers. You can get the crossovers for the Exact 4.3's new on Ebay for $39.99. I was told they are the same as the 5.3 Xovers. The 6.3's are different. As you can see they are in great shape. This would be nice for a old school setup, or someone looking for some bad *** Comps at a low price. Looking to get $125 shipped
EXACT5 Midrange / Woofer
The EXACT5 represents a departure from typical midrange/midbass drivers by combining
massive midbass and exceptionally smooth midrange.
· Die-cast Magnesium Frame designed specifically for extra long excursion. Results in higher
output and extended low frequency response.
· Copper Inductance Cap for lower distortion and extended high frequency response.
· Natural Fiber Cone designed for optimum rigidity and damping with minimal “coloration”.
EXACT1 Soft Dome Neodymium Tweeter
The EXACT1 tweeter is an ultra-high performance 1” Neodymium tweeter designed to deliver
outstanding high frequency reproduction.
· Fourth-generation Neodymium Magnetic Assembly providing performance comparable or
superior to tweeters three times the size.
· Specially-treated Textile Dome for a natural, smooth response to 20 kHz.
· Ferrofluid-immersed Voice Coil enhances heat dissipation.
EXACT5.3X Passive Crossover Network
The EXACT5.3X Passive Crossover represents a new concept in crossover philosophy. The
EXACT5.3X crossover consists of high quality, multi-element components with two switchable
functions. A three position switch controls the tweeter level and a two position switch controls the
midrange presence. The combination of each allows for a multitude of control options. Dual
inputs allow for multi-channel amp operation of woofer and tweeter circuits.
· 24 dB/octave Acoustic Summation Crossover Slopes for smoother response.
· Variable Tweeter and Midrange Controls for added flexibility.
· Dual Inputs for multi-amp operation and further flexibility.
· Dynamic Tweeter Level Control allows for improved power handling and continuous
output.
· Ultra-low DCR Inductors for minimal signal loss (High power Air-core type in woofer path).
· Mylar Film Capacitors to ensure low saturation and accuracy in the high frequencies.
EXACT5
.3 System Specifications
Frequency Response 40 Hz - 20,000 Hz ±3dB
Sensitivity 90 dB SPL at 1 meter (2.83v)
96 dB SPL at .5 meter (2.83v)
Continuous Power Handling 80 watts
Peak Program Power Handling 160 watts
Nominal Impedance 4W
Crossover Slope Rate 24 dB/octave ASC
Crossover Dimensions 3.25” (W) x 1.5” (H) x 5.125” (D)
EXACT6 Midrange/Woofer
Frequency Response 40 Hz - 6,500 Hz ±3dB
Continuous Power Handling 80 watts with EXACT5.3X Crossover
Peak Program Power Handling 160 watts with EXACT5.3X Crossover
Sensitivity 90 dB SPL at 1 meter (2.83v
Nominal Impedance 4W
Nominal Driver Diameter 6 1/2”
Mounting Cut-Out Diameter 5 5/8”
Mounting Depth 2 7/8”
Frequency Response 2,500 Hz - 20,000 Hz ±3dB
Sensitivity 90 dB SPL at 1 meter (2.83v)
Nominal Impedance 4W
Nominal Tweeter Diameter 1”
Mounting Cut-Out Diameter 1 7/8”
Mounting Depth (flush mount) 1/2”
EXACT5 Midrange / Woofer
The EXACT5 represents a departure from typical midrange/midbass drivers by combining
massive midbass and exceptionally smooth midrange.
· Die-cast Magnesium Frame designed specifically for extra long excursion. Results in higher
output and extended low frequency response.
· Copper Inductance Cap for lower distortion and extended high frequency response.
· Natural Fiber Cone designed for optimum rigidity and damping with minimal “coloration”.
EXACT1 Soft Dome Neodymium Tweeter
The EXACT1 tweeter is an ultra-high performance 1” Neodymium tweeter designed to deliver
outstanding high frequency reproduction.
· Fourth-generation Neodymium Magnetic Assembly providing performance comparable or
superior to tweeters three times the size.
· Specially-treated Textile Dome for a natural, smooth response to 20 kHz.
· Ferrofluid-immersed Voice Coil enhances heat dissipation.
EXACT5.3X Passive Crossover Network
The EXACT5.3X Passive Crossover represents a new concept in crossover philosophy. The
EXACT5.3X crossover consists of high quality, multi-element components with two switchable
functions. A three position switch controls the tweeter level and a two position switch controls the
midrange presence. The combination of each allows for a multitude of control options. Dual
inputs allow for multi-channel amp operation of woofer and tweeter circuits.
· 24 dB/octave Acoustic Summation Crossover Slopes for smoother response.
· Variable Tweeter and Midrange Controls for added flexibility.
· Dual Inputs for multi-amp operation and further flexibility.
· Dynamic Tweeter Level Control allows for improved power handling and continuous
output.
· Ultra-low DCR Inductors for minimal signal loss (High power Air-core type in woofer path).
· Mylar Film Capacitors to ensure low saturation and accuracy in the high frequencies.
EXACT5
.3 System Specifications
Frequency Response 40 Hz - 20,000 Hz ±3dB
Sensitivity 90 dB SPL at 1 meter (2.83v)
96 dB SPL at .5 meter (2.83v)
Continuous Power Handling 80 watts
Peak Program Power Handling 160 watts
Nominal Impedance 4W
Crossover Slope Rate 24 dB/octave ASC
Crossover Dimensions 3.25” (W) x 1.5” (H) x 5.125” (D)
EXACT6 Midrange/Woofer
Frequency Response 40 Hz - 6,500 Hz ±3dB
Continuous Power Handling 80 watts with EXACT5.3X Crossover
Peak Program Power Handling 160 watts with EXACT5.3X Crossover
Sensitivity 90 dB SPL at 1 meter (2.83v
Nominal Impedance 4W
Nominal Driver Diameter 6 1/2”
Mounting Cut-Out Diameter 5 5/8”
Mounting Depth 2 7/8”
Frequency Response 2,500 Hz - 20,000 Hz ±3dB
Sensitivity 90 dB SPL at 1 meter (2.83v)
Nominal Impedance 4W
Nominal Tweeter Diameter 1”
Mounting Cut-Out Diameter 1 7/8”
Mounting Depth (flush mount) 1/2”
