Newest Argent Audio Prototype

[Argent Audio 10+ year member]

Newest version of the KH501 Series Subs.

Woven Leads...

Magnet Boot

Aluminum Dust Cap with Logo

12" double 156mm magnet 2.5" D2 Coil

Fs 30.9 Hz

Re 1.55 Ohm per coil

Qms 5.29

Qes .47

Qts .43

Mms 161.1g

Cms 1.593 mm/N

Sd 480 cm^2

Vas 51.4l

Bl 14.6 N/A

Xmax 17.5mm

500 Watts RMS

10inch $154.99 Retail - $189.99

12inch $164.99 Retail - $199.99

15inch $179.99 Retail - $219.99

Click to read more...



[Spooney 10+ year member]

Looks nice. Whats the rated power handlings on these? Are those prices msrp or actual selling price? Looks like another decent option at the 150 to 200 price point.



[Argent Audio 10+ year member]

They are 500 Watts RMS and I updated the prices so it is clear...



[GetLikeMe 10+ year member]

Nice man, I just never been a fan of the inverted dustcaps.



[Argent Audio 10+ year member]

Back to the top...



[Papermaker85 5,000+ posts]

what alignments are recommended? what market is it based around? 500rms with a 42mm coil? seems like she will do nicely...



[Argent Audio 10+ year member]

what alignments are recommended? what market is it based around? 500rms with a 42mm coil? seems like she will do nicely...

This driver can work well in both sealed and ported enclosures. In a ported enclosure it truly thrives and really comes to life. I am still doing a bit of testing on what are the sweet sports, the ranges are what follows below:

10 Inch Sealed - .3-.5 Cubes

10 Inch Ported - .8-1.5 Cubes

12 Inch Sealed - .8-1.25 Cubes

12 Inch Ported - 1.8-2.5 Cubes

15 Inch Sealed - 2.25-3 Cubes

15 Inch Ported - 3-5 Cubes



[brmcm15 10+ year member]

nice



[loud-n-low 10+ year member]

any higher power handling models in the future? (high xmax, low fs)



[SPLaudio 5,000+ posts]

looks ok. not a big fan of inverted dust caps eather because i want the former sticking up at least 12mm thru the cone and fill that with epoxy.



[misfit138 5,000+ posts]

Didn't the Argent Audio guy mention some months back that these subs are OEM'd by Fi?



[SPLaudio 5,000+ posts]

yup



[misfit138 5,000+ posts]

Can't believe I remembered that. //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[Argent Audio 10+ year member]

Didn't the Argent Audio guy mention some months back that these subs are OEM'd by Fi?

Yes, they are Fi built.



[misfit138 5,000+ posts]

Send me a pair of 12"s (dual 4) and I'll test them & spread the word...
