My very first slot port design.

[James Bang 5,000+ posts]

I just tried to design my very own slot port design, and i think it looks like it should be correct, but being my first time, i think it may need some checking. If it's possible, i'd like for some of you experienced designers to double check this plan.

This will be for a 15 Fi Q / SI Mag 15

3.5 cubes after sub+port displacement. sub disp: .19cuft

Tuning will be approx 29.3hz

outer dimensions are 36.5" wide x 17" deep x 16.5" tall

port width x height: 3" X 15"

port length: 33.25"

here's a pic of the layout of the port. i drew a line through the center of the port for the port length... (hopefully that's the correct thing to do.)

thanks.

Click to read more...



[James Bang 5,000+ posts]

happy memorial day?



[profundus-sanus 10+ year member]

add 45's to the corners...other than that it looks good



[James Bang 5,000+ posts]

sweet. I'm hoping that it's correct w/ minimal flaws. I hope to make more designs in the future, so i wanna know if i'm on the right track.



[profundus-sanus 10+ year member]

To put in the 45's i make an angle axis thats 135 degrees from the port board then make a line thats port width long on that axis. Then add another axis thats 90 degrees to that then draw a line between the two outside boards on the new axis. Then thats what size the big side of the 45's should be.

like this

your port measurement is correct. i got 3.52 cubes net.

i got a 29.8hz tuning. but its not far enough off to make a major difference.



[James Bang 5,000+ posts]

thanks for the reply. I understand the technique you did w/ the 45s, good info.

as for the volume and tuning, i'm happy with that result. they're not too far off. Thanks again.



[James Bang 5,000+ posts]

//content.invisioncic.com/y282845/emoticons/woot.gif.aaa6090e619a97b6090d16dd863c5a69.gif

successful on my first design.

or am I?



[sqhertz 5,000+ posts]

how did you come up with the numbers for this box? pen and paper or programs...im dying to learn how to design.



[Zxcvtypo 10+ year member]

Looks good, will the sub be firing up or on the side of the port?



[James Bang 5,000+ posts]

i'm too lazy to use pen/paper.

i use two websites to help and then i use sketchup to lay it out and help w/ dimensions.

I use this site for measurements/volume help:

http://www.the12volt.com/caraudio/boxcalcs.asp#por

and this site for port length help:

http://www.carstereo.com/help/Articles.cfm?id=31

and a trusty calculator for port and sub displacement.

it was a little harder then i thought. Maybe because it was my first time, but it wasn't that bad. profundus-sanus approves so far, so this way works i guess.



[James Bang 5,000+ posts]

Looks good, will the sub be firing up or on the side of the port?

thanks.

the sub and port will be on the same panel. this design is for a scion xB, both sub and port firing upward.



[James Bang 5,000+ posts]

here's the rest of the design if anyone want's to use it.



[elkiko2004 10+ year member]

what software do tou use to do that plans ?? and where can i get it



[James Bang 5,000+ posts]

sketchup.. you can get it free from google.

http://www.sketchup.com/



[bigdog829 10+ year member]

Nevermind found the tut.
