Davecubs14's spl thread

[Davecubs14 10+ year member]

I may not have much to update right now but i'm making this thread to list my spl scores, gains, equipment used and get help/advice. And I have to thank my girlfriend for helping me with anything and everything possible. Just ask boomsday

I have not started on a strict burp box yet. But soon. Right now this is what i'm rocking...

2001 blazer s10

Pioneer DEH-P510UB

Atmos audio exo 15, box 4.5 cu.ft. tuned ~38

Audioque 2200d.

Xs power 5100 up front. 3100 in back.

330 Singer alt.

2 runs of ofc 1/0 wire. (Though they are cut up and connected at various points )

Big 3 in knu cca 1/0.

I will say....the exo is louder to the ear than my hdc3 was.

I think that's about it right now. I'm planning on running in meca, street 2 again this year.

Spl gains from today. I didn't do it at full power. Volume was @25 and I used a 100-20 hz tone each time.

At full volume - 144.3 @40hz before finding a few more .x dbs

All sealed - 135.5@55 hz

Driver door open - 137.4@38hz

Driver side triangle window open - 137.8@38hz

Both triangle windows open - 138.2@40hz

Passenger visor half way down - 138.3@40hz

Box 6" from hatch - 138.4@40hz

both mats hard side up - 138.5@40

Bracing the passenger door - 138.54@40hz

Lost on passenger door open.

Any other movements of the box.

both visors moved

just the driver side mat hard side up

any of the sunroof

bracing the hatch and the sides.

Click to read more...



[dragon.breath 10+ year member]

nice. let me know if you want to try some higher power testing. we will throw my saz3000d on it.



[sacsking916 5,000+ posts]

//content.invisioncic.com/y282845/emoticons/clap.gif.178cba2c538c68e720c727fcb024b19c.gif nice one bro. tuned in for more results. have you tried glovebox open? rearview mirror turned? passenger seat moved all the way up and tilted, straight and leaned back. those are just a couple for ya to try out



[Davecubs14 10+ year member]

nice. let me know if you want to try some higher power testing. we will throw my saz3000d on it.

That would be a very nice thing to do. Because in street 2, the max you can have is 3000 watts.

//content.invisioncic.com/y282845/emoticons/clap.gif.178cba2c538c68e720c727fcb024b19c.gif nice one bro. tuned in for more results. have you tried glovebox open? rearview mirror turned? passenger seat moved all the way up and tilted, straight and leaned back. those are just a couple for ya to try out

Thanks man. I need to do rearview mirror and steering wheel. I messed with the seats a lot. I know the visors are a no no for meca. I think the same goes for the glovebox...



---------- Post added at 07:09 PM ---------- Previous post was at 07:09 PM ----------



I'm also in the middle of doing a burp box for my massive dmx 15.



[ahole-ic]

Dave, I have lots of blazer tips. I have the same one. Remember, low power testing is fine for finding your approximate peak but not much else. At full power your frequencies will change and the effects your tweaks have will too. Go test at full power and you'll see what I mean.



[Davecubs14 10+ year member]

Dave, I have lots of blazer tips. I have the same one. Remember, low power testing is fine for finding your approximate peak but not much else. At full power your frequencies will change and the effects your tweaks have will too. Go test at full power and you'll see what I mean.

I'd love to hear some tips form another blazer owner

But yes, at full volume, it peaked @40

I tested at volume 25 because a few clicks below that and it peaked @55

After gaining the first 1.2 on low power, I tested it at full power and it went up 1.1 db's. So it seemed to be working.



[ahole-ic]

I'd love to hear some tips form another blazer owner
But yes, at full volume, it peaked @40

I tested at volume 25 because a few clicks below that and it peaked @55

After gaining the first 1.2 on low power, I tested it at full power and it went up 1.1 db's. So it seemed to be working.

Are you sealed on the dash, cabin open in the kick, or cabin open at headrest?



[Davecubs14 10+ year member]

Are you sealed on the dash, cabin open in the kick, or cabin open at headrest?

All tests except one was cabin open @ headrest.



[ahole-ic]

ygpm



[Davecubs14 10+ year member]

Thanks for your advice man. I'll try stuff out either way



[SPL Blazer 10+ year member]

Is this a 4 door Blazer, or the 2 Door? Leather interior or cloth? I have the 4 Door model with the cloth interior and peaked at 51 Hz sealed at the glass and 53 Hz with the door open in the kick. We don't have MECA up here so I never tried it at the headrest, but I'd be surprised if the resonant freq changed that much from the glass to the headrest. Going from leather interior to cloth changes it a little too. Playing with the rearview mirror won't do much good either, when you play it at full volume the mirror tends to move, and eventually break off the glass....happened so many times now that I just pull it off during testing or burping.



[Davecubs14 10+ year member]

Ok. Swapped the exo and hdc3 yesterday. Same box. Same speaker wires.

Didn't do much testing. But the hdc3 was a whole db louder than the exo. On a full burp, my voltage was a lot lower than when I tested the exo too. I could set the volume at 32 with no clipping. But yesterday, the highest I could go without clipping was 30.

Tested @ volume 25. The exo never reached 139.x's While the hdc3 did with just the door open.

I tested mainly the same things and got the same results. Just a full db higher. One thing I did try was lowering the back seats and nothing happened when I let the driver back seat down(when the meter was in the driver seat). But lost on the opposite back seat. The hdc3 also peaked @ 42 hz, 95% of the time. The exo, 40hz.

In the end. The exo is much louder to the ear imo. But the hdc3 got lower and moved my windshield more

Something else to add - My hdc3 is not the newer one. It has been beatin on for 3 years now



[Davecubs14 10+ year member]

Is this a 4 door Blazer, or the 2 Door? Leather interior or cloth? I have the 4 Door model with the cloth interior and peaked at 51 Hz sealed at the glass and 53 Hz with the door open in the kick. We don't have MECA up here so I never tried it at the headrest, but I'd be surprised if the resonant freq changed that much from the glass to the headrest. Going from leather interior to cloth changes it a little too. Playing with the rearview mirror won't do much good either, when you play it at full volume the mirror tends to move, and eventually break off the glass....happened so many times now that I just pull it off during testing or burping.

2 door. I tested a little with the rearview mirror. Didn't really gain nor lost anything. I peak a few hz higher on the dash. And it's cloth on the inside. No leather

I also want to pick your brain sometime about the front stage of a blazer



[SPL Blazer 10+ year member]

2 door. I tested a little with the rearview mirror. Didn't really gain nor lost anything. I peak a few hz higher on the dash. And it's cloth on the inside. No leather
I also want to pick your brain sometime about the front stage of a blazer

For my front stage I have a pair of 4" separates in the kick and 6.5" midbass in the factory locations in the doors, all RF Fanatic Q series and powered by RF Power series amps. I used to have them running through a Rockford EPX2 processor, but the bass kept killing it so I pulled it out.
