CVR box design

[jlanebpc 10+ year member]

I have 2 kicker cvr 12's, bout to build a ported box for them

My Max space available is 37x19x14

I was thinking not go go that big and go with 2 @ 35

Any and all input is greatly appreciated! Thanks!

Click to read more...



[09civic 5,000+ posts]

2 as in cubes? no.



[RAM_Designs 5,000+ posts]

You don't have enough space to port a pair of those subs.



[jlanebpc 10+ year member]

How big do I need, I can make it taller if needed



[Buck 5,000+ posts]

4 cubes at 34 hz. To have proof I know what I'm talking about, here's a box I designed for 8 of them:



[jlanebpc 10+ year member]

4 cubes per? The max dimensions I believe for CCDs is 2.25 per



---------- Post added at 06:48 PM ---------- Previous post was at 06:48 PM ----------



Cvr*



[Kangaroux 5,000+ posts]

no he means the total net should be 4 cubes. if you are tight on space i suggest investing/making some aero ports



[RAM_Designs 5,000+ posts]

4 cubes per? The max dimensions I believe for CCDs is 2.25 per

---------- Post added at 06:48 PM ---------- Previous post was at 06:48 PM ----------



Cvr*

4ft^3 for both subs after all displacements.



[Buck 5,000+ posts]

4 cubes total, 34 hz. 2 4" or 6" aero, you'll be happy.



[jlanebpc 10+ year member]

anyone have pics or a design to get me started ?
