I have these TS parameters saved in cpu memory from years ago when I was planning to purchase, but I never bought one. I copied them off of another forum thread I read about these subs. I never got these from a manual or anything, so you might want to check into it a little closer.
Fs 23 Hz
Vas 80 Liters
Qms 4.36
Qes .39
Qts .358
Znom 4 ohms
Re 2.8 ohms
Mms 197 g
Sd 74.4 sq.in
Pnom 800 watts
Mounting Depth:Gasket on - 6 9/16" (6.5625")Gasket off - 6 11/16" (6.6875")
