2009 Nissan GTR- SQ build

[customaudioman 10+ year member]

This was a local build I did late august of this year.

vehicle- 2009 Nissan GT-R

Source- OEM Navigation unit

Front stage - Morel elate 3-way limited edition component set (active)

processing- Mosconi 6to8

Amplifiers - Mosconi one 120.4 and (2) Mosconi one 240.2

Sub- Illusion Audio Carbon c12 sub woofer

Click to read more...



[customaudioman 10+ year member]

Here are pictures of the Morel limited edition components



[customaudioman 10+ year member]

I first started with the removal of door trim pieces and door panel.



[argenis69 10+ year member]

Beautiful car. Let's switch cars //content.invisioncic.com/y282845/emoticons/wink.gif.608e3ea05f1a9f98611af0861652f8fb.gif



[customaudioman 10+ year member]

Next I modified door sail were the stock tweeter resides to fit the new custom made machined tweeter pods. which flows well with interior accents.



[customaudioman 10+ year member]



[customaudioman 10+ year member]

next 3 sets of speaker wires were routed through both doors



[customaudioman 10+ year member]

Next the trim adapter rings were routed and coated for the door and door panel.

The new components compared to the old OEM components



[customaudioman 10+ year member]

Next the door was covered with focal bam xxxl and blackhole tile.



[customaudioman 10+ year member]

Then the mid bass adapter and mid bass were mounted to the door.



[customaudioman 10+ year member]

The mid range was attached to door panel and the panel received focal Bam xxxl mat.



[customaudioman 10+ year member]

The same treatment for the driver side was performed on the passenger side.



[customaudioman 10+ year member]

Next speaker wires, remote wire( fused at fuse box) and 0 gauge power wire are routed on the driver side.



[customaudioman 10+ year member]

full range signal was tap into at the OEM amp for signal to the Mosconi 6to8.

Also applied focal bam xxxl to fender areas and noisy sheet metal areas.



[customaudioman 10+ year member]

Moving on to the building process of the mdf enclosure. enclosure size is 1cu ft.
