(1) CDT-CL6 midbass driver

[BassAddictJ 5,000+ posts]

1. Product:

CDT CL-6

2. Specs:

•Power Handling: 80 Wrms (110W pk)

•Nominal Impedance: 4 Ohms

•Specifications Box Volume = 0.5 cu. Ft.

(8.5 liters) sealed

•Diameter: 6.5 (170mm)

•Sensitivity: 91.3 dB

•Frequency Response: 50 ~ 5000 hZ

•Voice Coil Diameter: 1.0" (26mm)

•Mounting depth 2.63 (66.8 mm)

•Outer diameter 6.63 (168 mm)

•Cutout diameter 5.78 (147 mm)

•Thiele-Small Paramters

•Free Air Resonance: 54 Hz

•Voice Coil DC Resistance: 3.2 ohms

•Voice Coil Inductance @ 1 kHz: 0.50 mH

•Mechanical Q (Qms): 3.56

•Electrical Q (Qes): 0.653

Total Q (Qts): 0.552

•Compliance Volume (Vas): 14.43 l

0.509 ft3

•Moving mass, Diaphragm: 15.57 Gr

•Driver Radiating Area (Sd): 135 cM2

20.93 In2

•Motor Force Factor: 5.09 Tm

3. Description/Condition:

Near mint condition. This was lightly used with it's cdt passives off 75w rms, so the woofer saw less than that. Aside from the mounting holes showing minimal wear this woofer is in excellent condition. looks and plays like new.

I had planned on getting another one of these and putting the pair in my car....however plans changed and i'll be sticking with my Illusion IM6's for a while //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif

4. Price: :

60 shipped, NO TRADES

price is firm....new online the cheapest these go for is $100 shipped

CDT Audio CL-6 6.5" Midbass Speakers 4 Ohm 80 RMS

5. Pictures:

Ref's: Years of selling here. You're in good hands

PM me with any questions

Click to read more...



[BassAddictJ 5,000+ posts]

ttt



[BassAddictJ 5,000+ posts]

ehh price OBO
