dross93ranger 10+ year member
CarAudio.com Elite
I am looking to trade or partial trade my SAX-50.4 for a nice headunit. I am also open to other items such as an 8" sub in small angled truck box, 6.5" component's, Audiocontrol units, small physical sized amps (mono preferably). You can also PM cash offers, but I am not set on getting rid of this and these are hard to find so I will have to come out ahead on this.
The SAX-50.4 was designed as a "little brother" to the SAX-100.4 for those that do not need as much power and/or have limited space to work with. The SAX-50.4 matches very well with the SAZ-1000D as a complete amplification system.
The same crossover features as the SAX-100.4 "C" revision are included.
SPECIFICATIONS:
4/3/2 Channel Bridgeable Class-AB Amplifier
MOSFET PWM Power Supply
Stable Into 4 Ohms Bridged or 2 Ohms Stereo Load
12dB Octave Electronic Crossover Slope
Variable Subsonic Filter
Independent 1/2 Channel High Pass Filter Variable with x 10 Range Selectable Switch
Variable 1/2 Channel Low Pass Filter with HPF/FULL/LPF Selectable Switch
Independent 3/4 Channel Low Pass Filter Variable with x 10 Range Selectable Switch
Variable 3/4 Channel High Pass Filter with HPF/FULL/LPF Selectable Switch
Independent 1/2 and 3/4 Channel Bass Boost Variable Control
Variable Bass-Boost Frequency Control
Variable Input Level Control
Input Sensitivity : 200mV ~ 6V
Subsonic Filter : 10Hz ~ 500Hz
Signal Input and Line Out RCA Connectors
Multi-Way Protection circuitry (Thermal/Over Current/Speaker Short/Speaker DC protection)
Tested Voltage & THD: 14.4V & Less than 0.05% THD
Operating Voltage : DC10V~16V Power Input
Wired Remote Controller
MSRP $349 USD
Rated power output
----RMS power, 4 ohm stereo
50W x 4CH
----RMS power, 2 ohm stereo
80W x 4CH
----RMS power, 4 ohm bridged
160W x 2CH
Signal to Noise Ratio >90dB
Low pass frequency crossover
50Hz~500Hz (CH1&2)
50Hz~5KHz (CH3&4)
High Pass Crossover
50Hz~5KHz (CH1&2)
50Hz~500Hz (CH3&4)
Variable Subsonic Filter 10Hz to 500Hz
Bass Boost 0~18dB
Variable Bass-Boost Frequency Control 35Hz to 120Hz
Frequency Response 10Hz ~ 40KHz (+/-1dB)
THD@RMS Watts
Channel Separation 75dB
Fuse Rating 25A x 2
Input Sensitivity Variable 200mV~6V (+/- 5%)
Dimensions 252(W) x 58(H) x 310(L)mm
The SAX-50.4 was designed as a "little brother" to the SAX-100.4 for those that do not need as much power and/or have limited space to work with. The SAX-50.4 matches very well with the SAZ-1000D as a complete amplification system.
The same crossover features as the SAX-100.4 "C" revision are included.
SPECIFICATIONS:
4/3/2 Channel Bridgeable Class-AB Amplifier
MOSFET PWM Power Supply
Stable Into 4 Ohms Bridged or 2 Ohms Stereo Load
12dB Octave Electronic Crossover Slope
Variable Subsonic Filter
Independent 1/2 Channel High Pass Filter Variable with x 10 Range Selectable Switch
Variable 1/2 Channel Low Pass Filter with HPF/FULL/LPF Selectable Switch
Independent 3/4 Channel Low Pass Filter Variable with x 10 Range Selectable Switch
Variable 3/4 Channel High Pass Filter with HPF/FULL/LPF Selectable Switch
Independent 1/2 and 3/4 Channel Bass Boost Variable Control
Variable Bass-Boost Frequency Control
Variable Input Level Control
Input Sensitivity : 200mV ~ 6V
Subsonic Filter : 10Hz ~ 500Hz
Signal Input and Line Out RCA Connectors
Multi-Way Protection circuitry (Thermal/Over Current/Speaker Short/Speaker DC protection)
Tested Voltage & THD: 14.4V & Less than 0.05% THD
Operating Voltage : DC10V~16V Power Input
Wired Remote Controller
MSRP $349 USD
Rated power output
----RMS power, 4 ohm stereo
50W x 4CH
----RMS power, 2 ohm stereo
80W x 4CH
----RMS power, 4 ohm bridged
160W x 2CH
Signal to Noise Ratio >90dB
Low pass frequency crossover
50Hz~500Hz (CH1&2)
50Hz~5KHz (CH3&4)
High Pass Crossover
50Hz~5KHz (CH1&2)
50Hz~500Hz (CH3&4)
Variable Subsonic Filter 10Hz to 500Hz
Bass Boost 0~18dB
Variable Bass-Boost Frequency Control 35Hz to 120Hz
Frequency Response 10Hz ~ 40KHz (+/-1dB)
THD@RMS Watts
Channel Separation 75dB
Fuse Rating 25A x 2
Input Sensitivity Variable 200mV~6V (+/- 5%)
Dimensions 252(W) x 58(H) x 310(L)mm
