WTB Subwoofers

[07BronzeFuz 10+ year member]

Guys I am looking for a 15 " d2 driver. I am open to all other sizes as long as the final load is 4 ohm. Looking to spend 150.00. My zip is 27856. Pls post pics up I am looknig more SPL than SQ. It will be in a ported box also no larger than 4-4.5 cu ft. I will have 700 watts to give it, Thanks

Click to read more...



[18inchjeepin 10+ year member]

Aq Hdc3 15 D2



[07BronzeFuz 10+ year member]

Aq Hdc3 15 D2

sure whats the spcs etc, i need to see pics



[18inchjeepin 10+ year member]

http://www.audioque.com/aq/HDCSeries.htm



[audio_phill 10+ year member]

Guys I am looking for a 15 " d2 driver. I am open to all other sizes as long as the final load is 4 ohm. Looking to spend 150.00. My zip is 27856. Pls post pics up I am looknig more SPL than SQ. It will be in a ported box also no larger than 4-4.5 cu ft. I will have 700 watts to give it, Thanks

http://www.caraudio.com/forum/showthread.php?t=424424

I'll do 150 for ya on the VooDoo, in 3 cubes @ 35Hz with a 3 x 15 x 12.5 port it has 5.26dB of gain giving a 1w/1m of over 90dB meaning wit only 700 watts it would still be darn loud. 118.5dB before cabin gain based soley on gain from power (700 watts = almost 28.5dB of gain from power) Would be hard to get louder for the money.



[07BronzeFuz 10+ year member]

bump, audio I may get with you on that. Just dont know a lot of voodoo? I have seen some on ebay.



[audio_phill 10+ year member]

VooDoo is a hybrid of Crystal Mobile Sound and VooDoo, The cones, Spiders, Surround, etc are Crystal, the frame is the widely available 12 spoke everyone uses and the motors as far as I can tell are a custom tooled version of the Overhung Crystal motor making it a VooDoo exclusive. Suspension wise, look to get 2" of usable stroke. 2.5" if you dont mind a lil suspension noise (spider pulling tight.) Also, later on down the road if you get the SQ bug, it'll do 20Hz all day in 4 cubes @ 22Hz and is stupid flat from 23Hz up with only +/-1dB, and a 3dB down of 19Hz.



[audio_phill 10+ year member]

Heres some more pics of the motor and suspension.



[audio_phill 10+ year member]

Heres the Website: http://www.voodoocaraudio.com/productsSubwoofersVW152D.html

Actual specs of this exact woofer are:

Note these are pre-break-in so Fs, Qts and Qes will drop, Vas and BL will climb slightly through break-in.

Re = 4.2046 ohms

Fs = 27.1756 Hz

Zmax = 74.1004 ohms

Qes = 0.5618

Qms = 9.3397

Qts = 0.5300

Le = 5.1620 mH (at 1 kHz)

Xmax = 16mm (one way)

Diam = 310.0000 mm ( 12.2047 in )

Sd =75476.7656 mm^2(116.9892 in^2)

Vas = 63.2820 L ( 2.2348 ft^3)

BL = 23.6747 N/A

Mms = 438.6239 g

Cms = 78.1968 uM/N

Kms =12788.2451 N/M

Rms = 8.0190 R mechanical

Efficiency = 0.2124 %

Sensitivity= 85.2896 dB @1W/1m
