The shitty wiring jobs thread

[PESteele 10+ year member]

heres what mine looks like now im redoing it all this week. Dont even ask me what most of them are.

Click to read more...



[revrider1 5,000+ posts]

//content.invisioncic.com/y282845/emoticons/wow.gif.23d729408e9177caa2a0ed6a2ba6588e.gif , I have seen worse though



[PESteele 10+ year member]

most of its not even caraudio



[revrider1 5,000+ posts]

most of its not even caraudio

//content.invisioncic.com/y282845/emoticons/crazy.gif.c13912c32de98515d3142759a824dae7.gif , what is it...



[PESteele 10+ year member]

i still gotta figure that out give me a break



[revrider1 5,000+ posts]

Good luck, i once bought a car which had a wire kit already installed. It was nothing but a mess, had to rip everything completely out and start over...



[jujumantb 10+ year member]

My first real 2 amp install was worse, I got laughed at by a shop which wanted to charge me like $400 to redo it all. No thanks //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[zachzchw 5,000+ posts]

My ground d block is covered in electrical tape.....I lost the cover.

My amp is sitting on the floor behind the box......I have no amp rack.

My front doors have gaping holes in them- I have no front stage installed.

//content.invisioncic.com/y282845/emoticons/crap.gif.7f4dd41e3e9b23fbd170a1ee6f65cecc.gif//content.invisioncic.com/y282845/emoticons/blush.gif.99bc659ee2012b7d826165e26fb5eebe.gif



[revrider1 5,000+ posts]

My ground d block is covered in electrical tape.....I lost the cover.
My amp is sitting on the floor behind the box......I have no amp rack.

My front doors have gaping holes in them- I have no front stage installed.

//content.invisioncic.com/y282845/emoticons/crap.gif.7f4dd41e3e9b23fbd170a1ee6f65cecc.gif//content.invisioncic.com/y282845/emoticons/blush.gif.99bc659ee2012b7d826165e26fb5eebe.gif

//content.invisioncic.com/y282845/emoticons/crazy.gif.c13912c32de98515d3142759a824dae7.gif



[TypeRBass 10+ year member]

my power/ground wires are a giant mess right now.....they'll be cleaned up this week though..gotta make it look semi presentable for the giant show this upcoming weekend. but when you have 8 runs of 1/0 goin to a battery, plus 8 more 1/0 wires coming off that battery.....its bound to be a mess one way or another.



[Prowler573 5,000+ posts]

My ground d block is covered in electrical tape.....I lost the cover.
My amp is sitting on the floor behind the box......I have no amp rack.

My front doors have gaping holes in them- I have no front stage installed.

//content.invisioncic.com/y282845/emoticons/crap.gif.7f4dd41e3e9b23fbd170a1ee6f65cecc.gif//content.invisioncic.com/y282845/emoticons/blush.gif.99bc659ee2012b7d826165e26fb5eebe.gif

Umm...this may be a silly question but if it is the Dblock for your grounds why bother covering it at all? Not too much chance of a short if it is the ground block...



[SUB_URBAN 10+ year member]

my power/ground wires are a giant mess right now.....they'll be cleaned up this week though..gotta make it look semi presentable for the giant show this upcoming weekend. but when you have 8 runs of 1/0 goin to a battery, plus 8 more 1/0 wires coming off that battery.....its bound to be a mess one way or another.

yea you've got a good reason, I'll try and get pics of my buddied camaro its a wreck lol.

can you say 4 gauge wire going from the pillar next to the windshield and going up stapled to the roof all the way back to the hatch.



[zachzchw 5,000+ posts]

Umm...this may be a silly question but if it is the Dblock for your grounds why bother covering it at all? Not too much chance of a short if it is the ground block...

Seemed like a good thing to do.

Finishing temp installs at 2am+missing ground block cover= lots of electrical tape on the block.



[kpozr2 10+ year member]



[snoopdan 5,000+ posts]

This has surely been seen 1.5 million times so here it is once more

IT'S LOG!
