TC Sounds Underhung NeoRadial 18

[ciaonzo 5,000+ posts]

Item(s) for Sale:

18" TC Sounds beehive neo underhung D2

Item(s) Description/Condition:

This is for the complete 18" driver in beautiful physical and mechanical condition, no scratches or dents. Loud as ballz and more than I need. Specs below. If interested, I have coils and parts to build this motor up into other awesome drivers. We can work out the cost of those parts through PM.

Qts .33

Qes .35

Qms 6.9

Fs 27.9

Re 3.01

Vas 233L

mms 279G

cms 116 um/N

BL 20.7

Sens 93.5 1w/1m

1k RMS / 4k dynamic



Price:

$750 shipped.

Shipping and Miscellaneous Item Information:

UPS Ground, CONUS only.

Item Pictures:

Click to read more...



[ciaonzo 5,000+ posts]

A sample of what they can do.



[biggen_bd 10+ year member]

Just the one??



[ciaonzo 5,000+ posts]

Just the one??

Only one I have, bud.
Sorry, I know everyone loves pairs.



[ciaonzo 5,000+ posts]

Updated pics as promised.



[joeybutts 10+ year member]

Any T/S specs and overall dimensions on this Ciao? I've been looking for the right driver for an IB/oversized sealed install for a while for my vehicle. Thanks!



[ciaonzo 5,000+ posts]

Any T/S specs and overall dimensions on this Ciao? I've been looking for the right driver for an IB/oversized sealed install for a while for my vehicle. Thanks!

This is much better suited to a vented enclosure but certainly has what it takes as far as excursion and power handling are concerned to go for an IB install. You'll need EQ since the Qts is on the low end.
I tried like hell to find the spec sheet online but couldn't. I will have to plug them into the original listing above.



[joeybutts 10+ year member]

What enclosure specs would you recommend? I quickly played with WINisd and the easiest thing for me is an 11 cube enclosure (the trunk) and using the skipass as the port (~6x11) and tune to mid to high 20's.

WINisd optimum was approximately 4.5 cubes at 27-28hz.



[ciaonzo 5,000+ posts]

What enclosure specs would you recommend? I quickly played with WINisd and the easiest thing for me is an 11 cube enclosure (the trunk) and using the skipass as the port (~6x11) and tune to mid to high 20's.
WINisd optimum was approximately 4.5 cubes at 27-28hz.

Yep, that sounds about right. I think I was modeling something like 5-7 @ 22-25 for my tastes.
I think you'd be fine to try the IB install, just watch the power until you get familiar with it.



[innsanes 10+ year member]

is this the same as the tc 5100 pro?



[ciaonzo 5,000+ posts]

is this the same as the tc 5100 pro?

No, but they're very close in nature. Same cone, spiders and coil but the WW offset is a little different due to the 5100 motor having a taller magnetic gap. The 5100 is a tad more sensitive and will play down into the 20's with less effort.
Pro-5100 18″ Neo Driver | TC Sounds



[ciaonzo 5,000+ posts]

Neo



[The Camry]

I cant imagine the EM field on that thing. Don't get it near any silverware [emoji14]

Sent from my SGH-T999 using Tapatalk



[ciaonzo 5,000+ posts]

I cant imagine the EM field on that thing. Don't get it near any silverware [emoji14]
Sent from my SGH-T999 using Tapatalk

That's the beauty of this magnetic circuit, there's very little wasted flux showing up as stray field. It's all internal and focused on the coil. //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[ciaonzo 5,000+ posts]

Buy this beauty.
