TC OEM10 Enclosure Recommendations

[ThumpinTitan 10+ year member]

Alright i have a TC OEM 10" Sub and was wondering what is the biggest Sealed Enclosure i can go with

Specs say Small Sealed is .3 cubes and Large Sealed is .6 cubes, but ive seen these subs in bigger boxes on YouTube

This is going in place of my 40 seat (Front, Middle Seat) of my Nissan Titan

I can go 14" Wide 15" Deep and prefer not to go over 13" in Height

Oh and i will be using 3/4 MDF with a Double Baffle

Click to read more...



[ctmike 10+ year member]

i say stick with the .6cuft, they sound really good in that size box.



[rollerdj 10+ year member]

spy had his in about that size, and didn't like it to much. i happend to put mine yesterday in a ported box built to the jl10w7 specs (tuned to 38 and 1.25 cubes roughly) i'm very impressed with it in that box. that sub gets up and wangs hard in that box. and still sounds pretty good to IMO.



[ThumpinTitan 10+ year member]

spy had his in about that size, and didn't like it to much. i happend to put mine yesterday in a ported box built to the jl10w7 specs (tuned to 38 and 1.25 cubes roughly) i'm very impressed with it in that box. that sub gets up and wangs hard in that box. and still sounds pretty good to IMO.

Yeah i wanted to build a box to JL's specs since theyre close in size and power, not sure if that matters but it sounds like a good idea in my head lol



[ThumpinTitan 10+ year member]

Here's what i have to work with...



[rollerdj 10+ year member]

i think u could pull that off. get rid of the cup holder and frame work off and you could pull that off.



[ThumpinTitan 10+ year member]

i think u could pull that off. get rid of the cup holder and frame work off and you could pull that off.

I was planning on keeping the Frame so i'd have something to secure the box to the Truck without drilling holes into the floor

The Air Bag Module is under the Cupholder, i dont want to mess with it lol



[arsonbob 10+ year member]

Good call on not messing with the module.

I have one TC OEM 10" in a ported box that I planned to put two in, and after displacement its about 1.4 cubes at 37, and it rarely gets sloppy, and IMO is loud as fvck for being run off of only 600ish watts.

Might work for you, but of course I can't guaranty any results.

Edit: It only gets sloppy if I give it a shitty signal off of my stock headunit.



[ThumpinTitan 10+ year member]

Good call on not messing with the module.
I have one TC OEM 10" in a ported box that I planned to put two in, and after displacement its about 1.4 cubes at 37, and it rarely gets sloppy, and IMO is loud as fvck for being run off of only 600ish watts.

Might work for you, but of course I can't guaranty any results.

Edit: It only gets sloppy if I give it a shitty signal off of my stock headunit.

I like ported but Im not good at building ported boxes and i want to go Sealed on this one... Any clue if i can go bigger than .6 cubes?



[ThumpinTitan 10+ year member]

Bump, anyone else?



[SlainNothing 10+ year member]

i've used this driver in several configs:

0.3 was too small- not enough low end

1.0 was too big - the driver acted like it was in "way too big of box" sound.

1.25 @ 35 4"port -got loud. not sloppy yet not accurate. not my taste

0.76 @32 equalized +1 at 60hz in an ABC box hits the sweet spot for me.



[sqhertz 5,000+ posts]

i had mine in a .8 cuft, iirc.

12 x 12 x 12" with 3/4" mdf. whatever that breaks down to. while i had it resting on the back seat of my celica since my trunk was all banged up , it was very nice. loud , very accurate , and not sloppy at all. one of , if not , my favorite woofer. the looks of it also played a major factor in me liking it so much. theyre ****ing sexy.



[ThumpinTitan 10+ year member]

You guys think this enclosure will work?

Top still needs to be glassed



[titanle 10+ year member]

i have mine in a 0.7 cubic foot box, audiopulse revo 10".



[ThumpinTitan 10+ year member]

Ok guys, here's what i made... let me know what you think
