I know many of you have been bugging me for all of this information, so here it finally is! The pre-order for the new Skar Audio ZVX Series is now open and will remain open until they drive August 5th, upon which they will start shipping to you!
The first run of them will be available in 12"/15"/18" sizes and offered in D1 and D2 voice coil configurations. This line will be fully assembled upon arrival to the US ready to ship, with recone soft parts being kept in stock for you all. These tested extremely well and I am finally ready to release them! I have plans to release a 10" as well but those won't be in for around 5 months, where as these are due August 31st!
I will update this thread with more pics & video's as we produce them, but for now here you go!
To Pre-order : PayPal sales@skaraudio.com for the amount ($ x qty of woofers) and leave a note when paying with what voice coils you would like. Email or PM us on here with any questions or if you would like us to send you an invoice.
*ZVX Series*
RMS Power : 1500 watts
*Testing was done with the D2 15" Final Prototype pictured below.
Voice Coil : 3” / 8 Layer Flat Wound CCAW Coil
Triple Stack Ferrite Motor Slugs (200mm * 25mm)
20mm Top Plate
15mm Back Plate
6 Layer Poly Cotton Spider
Heavy Duty 8 Gauge Push Terminals
T/S Parameters
*Measured with a Dual 2 Ohm Subwoofer
*Basket will also be a gloss back
RMS Power : 1500 Watts
Xmax (One Way) : 28mm
Fs : 34.93 Hz
Bl : 39.690 N/A
Qms : 6.769
Qes : 0.547
Qts : 0.506
Spl : 83.3 dB
Cms : 21.148 uM/N
Mms : 981.697 g
Le : 3.47 mH
Vas : 267.8 L
Pricing
12" D2/D4
Pre-Order : $340.00
MAP : $420.00
MSRP : $530.00
15" D2/D4
Pre-Order : $360.00
MAP : $440.00
MSRP : $550.00
18" D2/D4
Pre-Order : $395.00
MAP : $480.00
MSRP : $590.00
Pictures
*Magnet Boots as seen in the rendering will be on all production models
The first run of them will be available in 12"/15"/18" sizes and offered in D1 and D2 voice coil configurations. This line will be fully assembled upon arrival to the US ready to ship, with recone soft parts being kept in stock for you all. These tested extremely well and I am finally ready to release them! I have plans to release a 10" as well but those won't be in for around 5 months, where as these are due August 31st!
I will update this thread with more pics & video's as we produce them, but for now here you go!
To Pre-order : PayPal sales@skaraudio.com for the amount ($ x qty of woofers) and leave a note when paying with what voice coils you would like. Email or PM us on here with any questions or if you would like us to send you an invoice.
*ZVX Series*
RMS Power : 1500 watts
*Testing was done with the D2 15" Final Prototype pictured below.
Voice Coil : 3” / 8 Layer Flat Wound CCAW Coil
Triple Stack Ferrite Motor Slugs (200mm * 25mm)
20mm Top Plate
15mm Back Plate
6 Layer Poly Cotton Spider
Heavy Duty 8 Gauge Push Terminals
T/S Parameters
*Measured with a Dual 2 Ohm Subwoofer
*Basket will also be a gloss back
RMS Power : 1500 Watts
Xmax (One Way) : 28mm
Fs : 34.93 Hz
Bl : 39.690 N/A
Qms : 6.769
Qes : 0.547
Qts : 0.506
Spl : 83.3 dB
Cms : 21.148 uM/N
Mms : 981.697 g
Le : 3.47 mH
Vas : 267.8 L
Pricing
12" D2/D4
Pre-Order : $340.00
MAP : $420.00
MSRP : $530.00
15" D2/D4
Pre-Order : $360.00
MAP : $440.00
MSRP : $550.00
18" D2/D4
Pre-Order : $395.00
MAP : $480.00
MSRP : $590.00
Pictures
*Magnet Boots as seen in the rendering will be on all production models
