port equation???

[sleazebagger 10+ year member]

Trying to figure out what the final length to cut this port.

thanks much

2.3ft^3 in each chamber tuned to 33hz, 4 " areo port

Click to read more...



[Buck 5,000+ posts]

I need:

Vb

Fb

Port diameter



[sleazebagger 10+ year member]

I need:
Vb

Fb

Port diameter

33hz

4" port

2.3ft. ^3



[Buck 5,000+ posts]

With flares 11.33, without flares 10.33, round to your liking.



[sleazebagger 10+ year member]

so i have another issue maybe someone can help me with...

the install sheet says the port needs to be one diameter( 4" ) from any walls and this...



[Buck 5,000+ posts]

They mean the opening of the port. The way you are showing it is fine.

Say like the port is 4" diameter. The port needs to be at least 4" away from the interior wall where the opening of the port is.



[SpeedEuphoria 10+ year member]

if your not accounting for sub or the actual port displacement volume inside the box, your tuning will be higher
