Absolute Symmetry™ Class AB Circuit
(U.S. Patent #6,294,959)
Differential, Noise-Cancelling Input Topology:
RCA jack inputs (low-level) and multi-pin jack (high-level)
On-board Crossover:
State-variable, 12dB/octave Butterworth with continuously variable cutoff frequency selection from 50 – 200 Hz. Configurable as Low-Pass or High-Pass
Preamp Output:
Pass-through type.
Speaker output connections:
Accept up to 8 AWG wire
+12V and Ground connections:
Accept up to 4 AWG wire
Specifications
Rated Power (mono):
120 W RMS x 1 @ 4 ohm (12.5V);
200 W RMS x 1 @ 2 ohm (12.5V)
THD at Rated Power:
S/N Ratio:
>104 dB referred to rated power (A-weighted, 20 Hz – 20 kHz noise bandwidth)
Frequency Response:
10 Hz – 25 kHz (+0, -1dB)
Damping Factor:
>200 @ 4 ohm / 50 Hz,
>100 @ 2 ohm / 50 Hz
Slew Rate:
± 22V/µs
Input Range:
200mV – 8V RMS
Dimensions:
9.8" x 9.25" x 2.36"
