The time has finally come! We just got word that our buildhouse is wrapping up production this week or early next week so we are opening pre-orders on our newest subwoofer line!
ETA: Due in Mid January
The line is rated @ 300 Watts RMS and has a 2" Voice Coil.
The name of this new line is the IVX. Our intention with this line was to create a reasonably priced subwoofer line that would easily be one of the top performers for its power range on the market. Just like our VVX line, you should have no problem pushing more then rated power.
To place a pre-order, email us (Kevin@skaraudio.com) or PM us on here and we will take care of you.
Available in D2/D4 Coils
Pricing
IVX-10 = $99.99 Shipped (Normal $119.99)
IVX-12 = $109.99 Shipped (Normal $129.99)
IVX-15 = $119.99 Shipped (Normal $139.99)
Recommended Enclosure Specs :
For the 15" the enclosure should be about :
2.5 sealed with heavy poly-fill stuffing (F3 around 40 Hz)
3.5 vented @ 35 Hz (F3 around 32 Hz)
12" enclosure:
1.0 sealed with moderate poly-fill stuffing (F3 around 50 Hz)
2.0 vented @ 35 Hz (F3 around 32 Hz)
10" enclosure:
0.5 sealed with no poly-fill (F3 around 60 Hz)
1.0 vented @ 35 Hz (F3 around 32 Hz)
T/S Paramters
All measurements are from the D2 Coil for reference (We will test D4 when they arrive in January)
10 / 12 / 15 Respectively Below
Fms : 36.7 / 27.9 / 24.6 Hz
Res : 66.0 / 65.1 / 66.0 Ohms
Re : 3.8 / 3.8 / 3.8 Ohms
Qms : 3.98 / 4.27 / 4.67
Qes : 0.49 / 0.45 / 0.51
Qts : 0.44 / 0.41 / 0.46
Rms : 8.1 / 6.8 / 7.1 Kg/s
Cms : 0.13 / 0.20 / 0.19 mm/N
Mms : 140.4 / 166.1 / 215.9 gr
Nref : 0.20% / 0.33% / 0.53%
Bl : 15.8 / 15.7 / 15.8 N/a
SPL : 85.0 / 87.2 / 89.2 dB
VAS : 20.4 / 71.3 / 186.9 L
Rp : 27.7 / 34.3 / 30.9 Ohms
Lp : 35.4 / 50.4 / 50.2 mH
Cp : 755.2 / 874.6 / 1064.3 uF
Le : 1.71 / 1.72 / 1.72 mH
Pictures
