How can I tell if a Treo subwoofer is an SSi or SSX

[jondoe82 10+ year member]

Can someone tell me what to look for to tell if a Treo subwoofer is a SSi or SSX series and is there also a way to tell if it's a 2 ohm or 4. Thanks

Click to read more...



[infamous_e46 5,000+ posts]

Get a digital multi meter and check the coils to see if they are 2 or 4ohm

And look for pictures of the motor (magnet stack and the rest of the goodies on the rear) for each sub

And they might have different baskets..... //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[jondoe82 10+ year member]

Thanks



[Safe_Cracker 10+ year member]

Throw up a pic and I will tell you //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif

Polo..//content.invisioncic.com/y282845/emoticons/biggrin.gif.d71a5d36fcbab170f2364c9f2e3946cb.gif



[1ndatrunk 10+ year member]

SSIs have a chrome magnet with no markings on them, SSXs have black rubber around the mag and actually say SSX on the bottom unless the sticker has been removed. The hole in the mag on SSis are about 2.5 in across since it has a 3" coil, SSXs hole is about 3.5" wide since it has a 4" coil. Use a dmm to test the ohms, but all SSxs are D2 unless special orders



[boomin spl 10+ year member]

one weighs about 20 pounds, the other about 60 pounds. hope you feel the weight difference. the ssx motor is about twice the size of the ssi



[Cravingbass123]

heres my ssx 18

can't find pics of my ssx 15 i had

btw if you can't tell the difference easily between an ssx and an ssi, then you shouldn't be driving a car or operating machinery lol



[Safe_Cracker 10+ year member]

Naaa but here was mine! Good to remove the rubber boot to cut down on heat saturation during the summer. Polo..



[Towncar 10+ year member]

If you had to ask, you probably should stay away from both woofers...



[1ndatrunk 10+ year member]

heres my ssx 18

can't find pics of my ssx 15 i had

btw if you can't tell the difference easily between an ssx and an ssi, then you shouldn't be driving a car or operating machinery lol

Hey do you still have that sub, or did you sell it?



[Safe_Cracker 10+ year member]

Dual SSI 10.22 on a strapped pair of Kicker SX1250.1 's @ 1 ohm

It was hot on both of those days and with a black car the subs started out hot (heat saturation) so I purposely turned the gains down to stop the magical smoke.

Polo..
