had a vision LOL

[playyamxz550 10+ year member]

So say you have a sub that needs 4 cubic ft ported....and you make one box tune to 30hz 2 cubic ft and the sub is inverted then you make another box around it thats 2 cubic ft and its tuned to 40hz......what would the outcome be lol I just though of this of the top of my head I never seen it done

Click to read more...



[Imtjnotu 5,000+ posts]



[BlactimusCrime 10+ year member]

thats a 6th order bandpass.... but with horrible volumes and tuning



[playyamxz550 10+ year member]

it would have 2 ports? just one would be 30hz the other would be 40hz and the sub would be in the middle



[playyamxz550 10+ year member]

ahahahahhahahhahahhhahhahahh that pic is mad funny i think its time for me to go to bed its bin a long day lol



[RAM_Designs 5,000+ posts]

So bascially it's just a box inside a box? Basically just a ported box firing into another ported chamber, also known as a series tuned 6th order BP.



[HighTQCummins 10+ year member]

i think what he is saying, is having 2 ports firing seperately, not into each other, which to me sounds just rediculous



[813thumper 10+ year member]

that would be a parallel chamber 6th order bandpass



[813thumper 10+ year member]

http://i701.photobucket.com/albums/ww12/AmiCreation/RD%20Audio%20HW%2015%206th%20Order/IMG_0323.jpg

http://i701.photobucket.com/albums/ww12/AmiCreation/RD%20Audio%20HW%2015%206th%20Order/IMG_0328.jpg



[RAM_Designs 5,000+ posts]

that would be a parallel chamber 6th order bandpass

Not if one box is inside the other, like he suggested. That'd mean the port of the main box would be firing into the other box, making it series tuned.



[-01limited- 10+ year member]

Not if one box is inside the other, like he suggested. That'd mean the port of the main box would be firing into the other box, making it series tuned.

I interpreted it as thumper said. I thought when he said inverted that means the face of the cone firing into a ported box, then another one around the ass of the sub ported going off the back side of the sub.



[RAM_Designs 5,000+ posts]

I interpreted it as thumper said. I thought when he said inverted that means the face of the cone firing into a ported box, then another one around the ass of the sub ported going off the back side of the sub.

I had too hard of a time following it, so I'll just assume you guys are right and I'm looking at it wrong. //content.invisioncic.com/y282845/emoticons/biggrin.gif.d71a5d36fcbab170f2364c9f2e3946cb.gif



[-01limited- 10+ year member]

http://i701.photobucket.com/albums/ww12/AmiCreation/RD%20Audio%20HW%2015%206th%20Order/IMG_0323.jpg
http://i701.photobucket.com/albums/ww12/AmiCreation/RD%20Audio%20HW%2015%206th%20Order/IMG_0328.jpg

I had too hard of a time following it, so I'll just assume you guys are right and I'm looking at it wrong. //content.invisioncic.com/y282845/emoticons/biggrin.gif.d71a5d36fcbab170f2364c9f2e3946cb.gif

Lol I see where it can be confusing tho. But the way I'm thinking is exactly like those pictures.

Opppppppppppp where ya at?



[813thumper 10+ year member]

Not if one box is inside the other, like he suggested. That'd mean the port of the main box would be firing into the other box, making it series tuned.

read through it again and i didnt see where he said one box inside another



[RAM_Designs 5,000+ posts]

read through it again and i didnt see where he said one box inside another

When he said "around it" I thought he meant around the whole box causing the main port to fire into the chamber of the other box, not just "over" the back end of the sub.
